TCL U-MATCH-R32 Series

131
TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
13
95016-001428
Input tube assembly
1
14
45801-000046
Lower right cover plate assembly of
evaporator
1
15
45801-000138
Evaporator upper right cover plate assembly
1
16
45014-002009
Middle partition component
1
17
45014-003522
Valve plate
1
18
45003-000202
Right side panel assembly
1
19
45014-002001
Right block
1
20
45014-002551
Air intake grille assembly
2
21
45014-003013
Air intake grille assembly
1
22
35004-001862
Electric control box component
1
23
35004-001826
Indoor control panel
1
24
45006-000354
Electric control box cover
1
25
45005-000512
Motor limit card
2
26
45005-000196
Motor bearing right buckle
1
27
25001-000196
Dual axis motor
2
28
45005-000232
Left buckle of motor bearing
2
29
45005-000511
Motor fixing seat
2
30
45008-000195
Wind turbine upper volute
2
31
45009-000015
Centrifugal fan
2
32
45008-000153
Wind turbine lower volute
4
33
45003-000092
Left side panel assembly
4
34
45003-000044
Left block
4
35
45801-000136
Evaporator left cover plate assembly
1
36
45004-000015
Chassis components
1
APPENDIX
Appendix 1 The Comparison Table of Celsius-Fahrenheit Temperature
Fahrenheit
display
temperature
(℉)
Fahrenheit(
℉ )
Celsius
(℃)
Fahrenheit
display
temperatur
e
(℉)
Fahrenhe
it (℉)
Celsius
(℃)
Fahrenheit
display
temperature
(℉)
Fahrenheit(
℉ )
Celsius
(℃)
61
60.8
16
69/70
69.8
21
78/79
78.8
26
62/63
62.6
17
71/72
71.6
22
80/81
80.6
27
64/65
64.4
18
73/74
73.4
23
82/83
82.4
28
66/67
66.2
19
75/76
75.2
24
84/85
84.2
29
68
68
20
77
77
25
86
86
30
Appendix 2 Temperature Sensor Resistance Value Table (℃--K)
℃
K Ohm
℃
K Ohm
℃
K Ohm
℃
K Ohm
‐20
115.266
20
12.6431
60
2.35774
100
0.62973
‐19
108.146
21
12.0561
61
2.27249
101
0.61148
‐18
101.517
22
11.5000
62
2.19073
102
0.59386
‐17
96.3423
23
10.9731
63
2.11241
103
0.57683
‐16
89.5865
24
10.4736
64
2.03732
104
0.56038
‐15
84.2190
25
10.000
65
1.96532
105
0.54448
‐14
79.3110
26
9.55074
66
1.89627
106
0.52912
‐13
74.5360
27
9.12445
67
1.83003
107
0.51426
