TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
15
3.1.3 Ceiling & Floor Type
model
TCC-12ZHRH/DV(02)
TCC-18ZHRH/DV(02)
TCC-24ZHRH/DV(02)
TCC-30ZHRH/DV(02)
TCC-36ZHRH/DV(02)
Indoor unit
TCC-12ZHRH/DVI(02)
TCC-18ZHRH/DVI(02)
TCC-24ZHRH/DVI(02)
TCC-30ZHRH/DVI(02)
TCC-36ZHRH/DVI(02)
Outdoor unit
TCC-12HH/DVO(02)
TCC-18HH/DVO(02)
TCC-24HH/DVO(02)
TCC-30HH/DVO(02)
TCC-36HH/DVO(02)
Type
heating pump
heating pump
heating pump
heating pump
heating pump
Control type
remote controller
remote controller
remote controller
remote controller
remote controller
Declared cooling capacity
btu/h
12500(6200~16600)
18000(2115~19050)
24000(7500～25500)
30000（7600~32000)
36000(10500～42000)
Declared heating capacity
btu/h
13500(6800~18400)
19800(2600~20820)
26900(7900～28500)
32000（9200~33200)
40000(11200～46000)
Declared cooling capacity
W
3770(600~4860)
5300(620~5580)
7030(2200～7500)
8790（2230~9380）
10550(3080～12300)
Declared heating capacity
W
4000(700~5400)
5800(760~6100)
7900(2320～8350)
9380（2700~9730）
11720(3280～13500)
Pdesignc
W
3770
5300
7030
8800
10550
SEER declared
W/W
6.1
6.3
6.2
6.2
6.1
Energy Class
A++
A++
A++
A++
A++
Pdesignh Average
W
4000
4300
5500
7400
8500
SCOP Average declared
W/W
4.00
4.00
4.0
4.0
4.0
Energy Class(Average)
A+
A+
A+
A+
A+
Declare capacity(-10℃)
W
3270
3650
5400
6550
7200
Back up heating capacity(-
10℃)
W
730
650
100
750
1300
Annual energy
consumption
Cooling
kwh/a
284
294
485
490
605
Average
kwh/a
1475
1505
2550
2550
2975
Moisture removal
Liters/h
1.5
1.5
2.00
2.5
3.60
Indoor sound
power(S/H/M/L/Mute)
dB(A)
59/54/52/49/45
59/54/52/49/45
64/61/57/53/50
63/61/58/55/50
65/61/59/55/52
Indoor sound
power(Standard rating
conditions)
dB(A)
54
54
61
61
61
Outdoor sound
power(Standard rating
conditions)
dB(A)
62
62
64
66
67
Indoor sound
pressure(S/H/M/L/Mute)
dB(A)
49/44/42/39/35
49/44/42/39/35
54/51/47/43/40
53/51/48/45/40
55/51/49/45/42
Indoor sound
pressure(Standard rating
conditions)
dB(A)
44
44
51
51
51
Outdoor sound
pressure(Standard rating
conditions)
dB(A)
52
52
54
56
57
Electrical Data
Power supply
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Power supply side
Outdoor
Outdoor
Outdoor
Outdoor
Outdoor
Voltage Range
V
176~265
176~265
176~265
176-265
176~265
Cooling
Operating
current
Indoor
A
0.6(0.2～1.0)
0.6(0.2～1.0)
0.85(0.2～1.0)
0.95(02-1.1)
0.8(0.3～0.9)
Outdoor
A
7.0(1.8～12.0)
7.0(1.8～12.0)
10.5(3.8～14)
12(3.8～14.9)
15.0(0.9～20.1)
Heating
Operating
current
Indoor
A
0.6(0.2～1.0)
0.6(0.2～1.0)
0.85(0.2～1.0)
0.95(02-1.1)
0.8(0.3～0.9)
Outdoor
A
8.0(1.6～11)
8.0(1.6～11)
11(4.0～13)
12.5(4.0～13.9)
15.3(1.3～16.1)
Cooling Power
consumption
Indoor
W
70(20～110)
70(20～110)
100(20～135)
120(20-155)
170(60～190)
Outdoor
W
1550(395～2740)
1580(395～2740)
2400(710～3165)
2700(710～3415)
3280(200～4410)
Heating Power
consumption
Indoor
W
70(20～110)
70(20～110)
100(20～135)
120(20-155)
170(60～190)
Outdoor
W
1750(350～2400)
1780(350～2400)
2550(745～2965)
2850(745～3215)
3330(290～3510)
Max.
powerconsump
W
2850
2850
3300
3600
4600
Max.current
A
13
13
15
16.5
21
Refrigerating
System
Refrigerant type/Charge/GWP/CO2
equivalent
R32/0.95kg/675/0.642tonnes
R32/0.95kg/675/0.642tonnes
R32/1.35kg/675/0.911tonnes
R32/1.4kg/675/0.944tonnes
R32/2.10kg/675/1.418tonnes
Compressor
Type
Rotary
Rotary
Rotary
Rotary
Rotary
