TCL U-MATCH-R32 Series User Manual

TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
16
Model
KSN140D53UFZ3
KSN140D53UFZ3
C-6RZ180H3AAF
C-6RZ210H3CDF
KTF240D43UMT
Indoor air circulation
Cooling/heating
m3/h
980/1050
980/1050
1200/1350
1550/1700
1950/2000
Indoor fan type
centrifugal fan
centrifugal fan
centrifugal fan
centrifugal fan
centrifugal fan
Indoor fan
speed
S/H/M/L/Mute
Cooling
rpm
1050/880/820/750/650
1050/880/820/750/650
1300/1150/1000/900/800
1300/1170/1050/950/800
1400/1200/1080/980/850
Heating
rpm
1050/880/820/750/650
1050/880/820/750/650
1300/1150/1000/900/800
1300/1170/1050/950/800
1400/1200/1080/980/850
Dry
rpm
750/750
750/750
900/900
850/850
980/980
Sleep
rpm
1050/880/820/750/650
1050/880/820/750/650
1300/1150/1000/900/800
1300/1170/1050/950/800
1400/1200/1080/980/850
Outdoor fan type
Propeller fan
Propeller fan
Propeller fan
Propeller fan
Propeller fan
Outdoor air circulation
m3/h
2550
2650
3500
4000
5000
Outdoor fan speed
rpm
730
770
880
950
930
External Static
Pressure(Rated )
Pa
0
0
0
0
0
External Static
Pressure(Range )
Pa
0
0
0
0
0
Connections
5*1.5mm²
5*1.5mm²
5*1.5mm²
5*1.5mm²
3*1.5mm²+3*0.75 mm²
Connecting
Wiring
Core x Size
outdoor：3*2.5mm²;
outdoor to indoor：5*1.5mm
²
outdoor：3*2.5mm²;
outdoor to indoor：5*1.5mm
²
outdoor：3*2.5mm²;
outdoor to indoor：5*1.5mm
²
outdoor：3*2.5mm²;
outdoor to indoor：
5*1.5mm²
outdoor：3*2.5mm²;
outdoor to indoor：3*1.5mm
²+3*0.75 mm²
Expension device
Capillary +EXV
Capillary +EXV
Capillary +EXV
Capillary +EXV
Capillary +EXV
Connecting
Pipe
Gas
Inches
3/8"
3/8"
1/2"
5/8"
5/8"
Liquid
Inches
1/4"
1/4"
1/4"
3/8"
3/8"
Application area
m²
15-25
20-35
27~45
35-60
39~71
Max. refrigerant pipe length
m
30
30
30
30
50
Max. difference in level
m
15
15
15
15
25
Operation temperature
range
℃
16-31
16-31
16-31
16-31
16-31
Ambient
temperature
range
Outdoor
℃
Cooling:-15-50/Heating:-15-
24
Cooling:-15-50/Heating:-15-
24
Cooling:-15-50/Heating:-15-
24
Cooling:-15-50/Heating:-
15-24
Cooling:-15-50/Heating:-15-
24
Indoor
℃
Cooling:17-32/Heating:0-30
Cooling:17-32/Heating:0-30
Cooling:17-32/Heating:0-30
Cooling:17-32/Heating:0-30
Cooling:17-32/Heating:0-30
Net
dimensions
(W x H x D)
Indoor
mm
1055x675x235
1055x675x235
1055×675×235
1275×675×235
1275×675×235
Outdoor
mm
780×605×307
780×605×307
845×700×342
845×700×342
910×804×378
Net weight
Indoor
kg
24
24
26
30
30
Outdoor
kg
30
30
40
41
55
Packing
dimensions
(W x H x D)
Indoor
mm
1130x748x305
1130x748x305
1130x748x305
1350x748x305
1350x748x305
Outdoor
mm
890×385×643
890×385×643
960×747×430
960×747×430
1022x855x480
w/i pipe
Outdoor
mm
/
/
/
/
/
Gross weight
Indoor
kg
29
29
31
35
35
Outdoor
kg
33
33
44
45
60
model
TCC-36ZHRH/DV7(02)
TCC-42ZHRH/DV(02)
TCC-42ZHRH/DV7(02)
TCC-48ZHRH/DV7(02)
TCC-55ZHRH/DV7(02)
Indoor unit
TCC-36ZHRH/DVI(02)
TCC-42ZHRH/DVI(02)
TCC-42ZHRH/DVI(02)
TCC-48ZHRH/DVI(02)
TCC-55ZHRH/DVI(02)
Outdoor unit
TCC-36HH/DV7O(02)
TCC-42HH/DVO(02)
TCC-42HH/DV7O(02)
TCC-48HH/DV7O(02)
TCC-55HH/DV7O(02)
Type
heating pump
heating pump
heating pump
heating pump
heating pump
Control type
remote controller
remote controller
remote controller
remote controller
remote controller
Declared cooling capacity
btu/h
36000(12000～52000)
42000(12000～45000)
42000(12000～52000)
48000(12000～52000)
55000(14000～57000)
Declared heating capacity
btu/h
40000(14000～58000)
46000(13000～51000)
46000(14000～58000)
55000(14000～58000)
62000(15000～67000)
Declared cooling capacity
W
10550(3520～15240)
12100(3520～13200)
12100(3520～15240)
14070(3520～15240)
16000((4100～16710)
Declared heating capacity
W
11720(4100～17000)
13500(3810～14950)
13500(4100～17000)
16120(4100～17000)
18170(4400～19640)
Pdesignc
W
10550
12100
12100
14000
16000
SEER declared
W/W
6.1
6.1
6.1
6.1
6.1
Energy Class
A++
A++
A++
A++
A++
Pdesignh Average
W
8500
9500
9500
11800
11900
SCOP Average declared
W/W
4.0
4.0
4.0
4.0
4.0
Energy Class(Average)
A+
A+
A+
A+
A+
Declare capacity(-10℃)
W
7000
7700
7700
9900
10840
