TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
17
Back up heating capacity(-
10℃)
W
1500
1800
1800
1900
1060
Annual energy
consumption
Cooling
kwh/a
620
694
705
820
931
Average
kwh/a
2960
3430
3360
4450
4129
Moisture removal
Liters/h
4.80
4.20
4.80
4.8
5.40
Indoor sound
power(S/H/M/L/Mute)
dB(A)
63/62/59/56/55
66/64/62/60/53
63/62/59/56/55
65/64/61/58/55
64/61/59/56/54
Indoor sound
power(Standard rating
conditions)
dB(A)
62
64
62
62
61
Outdoor sound
power(Standard rating
conditions)
dB(A)
70
68
70
70
68
Indoor sound
pressure(S/H/M/L/Mute)
dB(A)
53/52/49/46/45
56/54/52/50/43
53/52/49/46/45
53/52/49/46/45
54/51/49/46/44
Indoor sound
pressure(Standard rating
conditions)
dB(A)
52
54
52
52
51
Outdoor sound
pressure(Standard rating
conditions)
dB(A)
60
58
60
60
58
Electrical Data
Power supply
Indoor：220-
240V~/50Hz/1P
Outdoor：
380~415V~/50Hz/3P
Indoor：220-
240V~/50Hz/1P
Outdoor：220-
240V~/50Hz/1P
Indoor：220-
240V~/50Hz/1P
Outdoor：
380~415V~/50Hz/3P
Indoor：220-
240V~/50Hz/1P
Outdoor：
380~415V~/50Hz/3P
Indoor：220-
240V~/50Hz/1P
Outdoor：
380~415V~/50Hz/3P
Power supply side
Outdoor
Outdoor
Outdoor
Outdoor
Outdoor
Voltage Range
V
Indoor：176~265
Outdoor：304~458
176~265
Indoor：176~265
Outdoor：304~458
Indoor：176~265
Outdoor：304~458
Indoor：176~265
Outdoor：304~458
Cooling
Operating
current
Indoor
A
1.0（0.6~1.4）
0.85(0.4～1.0)
1.0（0.6~1.4）
1.0（0.6~1.4）
1.5（0.6~1.8）
Outdoor
A
7.1(1.7~9.8)
17.3（0.95～20.6）
6.3(1.7~9.8)
6.3(1.7~9.8)
9.2(1.9~11.0)
Heating
Operating
current
Indoor
A
1.0（0.6~1.4）
1.4(0.4～1.0)
1.0（0.6~1.4）
1.0（0.6~1.4）
1.5（0.6~1.8）
Outdoor
A
6.7(1.5~10.6)
16.6（1.41～17.2）
7.9(1.5~10.6)
7.9(1.5~10.6)
9.1(1.7~11.0)
Cooling Power
consumption
Indoor
W
310(80~380)
180(80～220)
310(80~380)
310(80~380)
210(80~240)
Outdoor
W
3260(920~5460)
3800（210～4520）
4590(920~5460)
4590(920~5460)
6000(1020~6440)
Heating Power
consumption
Indoor
W
310(80~380)
180(80～220)
310(80~380)
310(80~380)
210(80~240)
Outdoor
W
3080(800~5820)
3650（310～3780）
5090(800~5820)
5090(800~5820)
5960(920~6950)
Max.
powerconsump
W
7000
4650
7000
7000
7000
Max.current
A
12.0
21
12.0
12.0
12.0
Refrigerating
System
Refrigerant type/Charge/GWP/CO2
equivalent
R32/2.10kg/675/1.418tonn
es
R32/2.20kg/675/1.485to
nnes
R32/2.10kg/675/1.418ton
nes
R32/2.10kg/675/1.418tonn
es
R32/2.10kg/675/1.418tonn
es
Compressor
Type
Rotary
Rotary
Rotary
Rotary
Rotary
Model
C-7RZ320H3CCF
KTF240D43UMT
C-7RZ320H3CCF
C-7RZ320H3CCF
C-7RZ320H3CCF
Indoor air circulation
Cooling/heating
m3/h
2300/2300
2150/2150
2300/2300
2100/2200
2100/2200
Indoor fan type
centrifugal fan
centrifugal fan
centrifugal fan
centrifugal fan
centrifugal fan
Indoor fan
speed
S/H/M/L/Mute
Cooling
rpm
1280/1200/1100/1000/950
1250/1030/980/900/830
1280/1200/1100/1000/950
1280/1200/1100/1000/950
1320/1250/1150/1050/950
Heating
rpm
1280/1200/1100/1000/950
1250/1030/980/900/830
1280/1200/1100/1000/950
1280/1200/1100/1000/950
1320/1250/1150/1050/950
Dry
rpm
1000/950
830/830
1000/950
1000/950
1000/950
Sleep
rpm
1280/1200/1100/1000/950
1250/1030/980/900/830
1280/1200/1100/1000/950
1280/1200/1100/1000/950
1320/1250/1150/1050/950
Outdoor fan type
Propeller fan
Propeller fan
Propeller fan
Propeller fan
Propeller fan
Outdoor air circulation
m3/h
5600
5000
5600
5600
6000
Outdoor fan speed
rpm
700
930
700
700
720
External Static
Pressure(Rated )
Pa
0
0
0
0
0
External Static
Pressure(Range )
Pa
0
0
0
0
0
Connections
3×0.75mm²通讯线
3*1.5mm²+3*0.75
3×0.75mm²通讯线
3×0.75mm²通讯线
3×0.75mm²通讯线
Connecting
Wiring
Core x Size
Indoor：3×1.0mm²
Outdoor：5×2.5mm²
outdoor：3*2.5mm²;
outdoor to indoor：
3*1.5mm²+3*0.75
Indoor：3×1.0mm²
Outdoor：5×2.5mm²
Indoor：3×1.0mm²
Outdoor：5×2.5mm²
Indoor：3×1.0mm²
Outdoor：5×2.5mm²
Expension device
Capillary +EXV
Capillary +EXV
Capillary +EXV
Capillary +EXV
Capillary +EXV
Connecting
Gas
Inches
5/8"
5/8"
5/8"
5/8"
5/8"
