3. Connect two paralleling cables from top unit M connector to bottom unit S connector as
illustrated in Figure 10.












Figure10:Three20V‐40VUnitsParallelingCableConnection


4. Insert output cover through the cables as illustrated in Figure 11.


Figure11:OutputCoverInsertion


OutputCover

ParallelingCable

