2
1.1
General
Parallel kit is supplied separately from the power supply packing according to order.
The usage of parallel kit is according to customer's needs.
1.2
Advanced Parallel
For parallel connection, refer to advanced parallel chapter in the series User Manual.
1.3
Product Safety Instructions
Safety approvals are valid for single unit only. These are not valid for parallel kit assembly.
When using a paralleling kit with a protective bracket, it must be correctly assembled, as described
further in this document.
1.4
Assembly Instructions
The supplied kit is used for standard and blank panel options. Follow the instructions carefully
according to power supply model.
1.4.1
G/P-3U-10V - Assembly Instructions for three 10V units in Parallel
1.4.1.1
Components List
Image Component Quantity
10‐32x5/16PanHeadScrew,StainlessSteel 12
HelicalSpring‐LockWasher,No.10,StainlessSteel 12
PlainWasher,No.10,StainlessSteel 12
ConnectionPlate3U 2
OutputShort 2
