TDK-Lambda ZUP36-12 - Page 26

Rubber Bumpers:
4 places marked ‘B’ (removable)
3.11 OUTLINE DRAWINGS
ZUP 800W Series
DIMENSIONS:
140x124x350 mm.
WEIGHT:
5.8 kg.
20.0
22.0
22.0
30.0
46.3
47.0
External
Control
Connector
(Note3)
IEC320
AC Inlet
RS232/RS485
communication
connectors
REMOVABLE HANDLE
11.0
+
1.0
_
350.0
+
1
_
290.0
+
1
_
139.5
107.5
Mounting Holes: Tap M4 x 4 marked ‘A’
(See note 1)
Notes:
1. Mounting screws must not
protrude more than 6mm
into the power supply.
2. Use M8 or 5/16” screw for
load wires connection,
enclosed in the package
at time of shipment.
3. Receptacle: AMP, 87631-9,
14 contacts, double row.
Pin: 87523-5 or 87523-6.
140.0
+
0.5
_
+
0.5
_
124.0
+
1.0
_
99.6
201.50
+
0.5
_
59.5
10.4
B
B
B
A
A
A
A
118.90
_
+
0.5
B
18.5
POWER
20.0
+
1.0
_
131.0
