TEAC AD-RW900/900E
CAUTION
Part with numbers in parentheses ( ) cannot be ordered.
注意
"( )"付き品番は、発注できません。
- 23 -
Exploded View Parts List
REF.NO. PARTS NO. DESCRIPTION . QTY REMARKS
1 M02904500B CHASSIS,MAIN CDA550 G 1
2 M03032700A SHEET,BARRIER 8*120 TP G 1
3 B00199708A SCREW,BPB 3*8 FZB G 6
4 3M0047200A FOOT ASSY, SD-455 G 4
5 B00199708A SCREW,BPB 3*8 FZB G 4 FOOT
6 M02941400A SPACER,SUPPORT RAD-8 G 4
7 B00199708A SCREW,BPB 3*8 FZB G 6
8 B00198306A SCREW,BPS 3*6 FZC G 1
9 B00199708A SCREW,BPB 3*8 FZB G 4 CHA-BASE CD
10 3M0863700A BASE CD MECHA AD-RW900 G 1
11 3M0863800A BRACKET CD MECHA AD-RW900 G 2
12 B00197806A SCREW,PPSU 3*6 FZC G 6
13 B00198306A SCREW,BPS 3*6 FZC G
8
14 3M0880200A DVDRW MECH AD-7290H-TE G 1 (CD MECHA)
15 3M0875000A HOLDER,LCG-6 4
16 B00197806A SCREW,PPSU 3*6 FZC G 4 PCBMAIN-CHA
17
3E0836000A
TRANS POWER,AD-RW900 G
1
[AC 100V / 120V / 120-220V / 230V]
18 B00199508A SCREW,BPB 4*8 FZC G 4 PT-BASE CD
19 3M0259000B WASHER PC 6*3*0.5 G 2
20 3M0878700A BRACKET IC AD-RW900 G 1
21 3E040130 SW,SL14-22AH-0AN G (1) Only [T/C, EX] model
22 3M0863201A REAR PANEL AD-RW900 JPN G 1 [JPN]
3M0863293A REAR PANEL AD-RW900 EX/T/C G 1 [T/C]
3M0886900A REAR PANEL AD-RW900 EUR G 1 [EUR]
23 3M000880 BUSHING, #2271(CSA)-G 1
24 B00199808A SCREW,BPB 4*8 FZB G (2) Only [T/C, EX] model
25 B00198608A SCREW,BPS 3*8 FZB G 2
26 B00199708A SCREW,BPB 3*8 FZB G 2
27 B00199708A SCREW,BPB 3*8 FZB G 4
28 B00199708A SCREW,BPB 3*8 FZB G 3
29 3E017240G GND TERMINAL 1
30 B00199708A SCREW,BPB 3*8 FZB G 3
31 3M0025300C BRACKET,PCB(A) G AD500 1
32 3M0863410A BONNET AD-RW900 B G 1 BLACK
3M0863400A BONNET AD-RW900 S G 1 SILVER
33 B00197606A SCREW,PPSU 3*6 FZB G 4
34 B00170608A SCREW,VPCR 3*8 FZB G 3
35 M02788000A T LK WSHR,3D G 4
36 3M0863000A TRAY PANEL AD-RW900 B G 1 BLACK
3M0863010A TRAY PANEL AD-RW900 S G 1 SILVER
37 3M0863300A WINDOW LCD AD-RW900 G 1
38 3M0821800A BUTTON,POWER AD800 G 1 BLACK
3M0821810A BUTTON POWER AD-RW900 S G 1 SILVER
39 3M0051640A TEAC BADGE 1
40 3M0024620A KNOB REC VOL AD-800 G 1 BLACK
3M0863500A KNOB REC VOL AD-RW900 S G 1 SILVER
41 3M0010500B TORSION SPRING,CASE II G 1
42 3M0024800A KNOB,PHONE VOLUME AD500 G 2 BLACK
3M0024850A KNOB,PHONE VOLUM(SLIVER)G 2 SILVER
43 3M0011100A CASE,LEAD W-780R G 1
