Teac AD-RW900 - Page 37

PCB, GATHER-A AD-RW900 G / PCB, GATHER-B AD-RW900 G
   
REF.NO. PARTS NO. DESCRIPTION . REMARKS
S519 E0127100
SW,TACT SKHHAM2520 G
S523 E0127100
SW,TACT SKHHAM2520 G
S524 E0127100
SW,TACT SKHHAM2520 G
S525 E0127100 SW,TACT SKHHAM2520 G
S526 E0127100 SW,TACT SKHHAM2520 G
S527 E0127100 SW,TACT SKHHAM2520 G
S528 E0127100 SW,TACT SKHHAM2520 G
S529 E0127100
SW,TACT SKHHAM2520 G
S530 E0127100 SW,TACT SKHHAM2520 G
S509 3E082260 SW,SSSF023NC1-TK1 G
S520 3E082260 SW,SSSF023NC1-TK1 G
S531 3E082260 SW,SSSF023NC1-TK1 G
S532 E0174710 SW,SSSF022NC2-TK1 G
VR501 3R003980 VAR REG, 5KB RK11K113 CCG
S533 3E037310
ENCODER,EC12E24404A6 G
P1 3E082270 CONNECT USB04142051W00RS G
D501 S0065830
LED,SLR-342VR G
D502 S0065830
LED,SLR-342VR G
D503 S0065830 LED,SLR-342VR G
D501A 3M0125900A HOLDER,LED H=13 G
P119 3E083880 CONNECTOR,19FMN-BTRK G
Y551 3E083620 XTAL,12MHZ 18PF HC49S G
J705 M01510100A BRACKET,PCB-A G
J704 E0134440 OPT CONN,GP1FAV51RK0F G
J706 E0115760 CONN,USB UBB4RD14C4D G
G501 3M0876700B SPRING USB AD-RW900 G
J108 E0102470 CONNECTOR,B 6B-EH(LF)(SN)
PCBA,R-GATHER A AD-RW900 G
Q501 S0094422 TRANSISTOR,DTC124ESA G
Q502 S0094422 TRANSISTOR,DTC124ESA G
Q503 S0094422 TRANSISTOR,DTC124ESA G
3E95100601A PCBAGATHER-BJPNAD-RW900G
3E95100650A PCBAGATHER-BEURAD-RW900G
3E95100693A PCBAPHONEAD-RW900G
PCBA,A-GATHER B AD-RW900 G
D301 S0067021
DIODE,1SS133 T-77 G
D312 S0067021 DIODE,1SS133 T-77 G
L781 R0155291 RD,1/8W 10K OHMJ26MMG
L881 R0155291 RD,1/8W 10K OHMJ26MMG
L701 E0123241
JUMPER WIRE,5MM G
L801 E0123241
JUMPER WIRE,5MM G
D711 E0123271 JUMPER WIRE,7.5MM G
D811 E0123271 JUMPER WIRE,7.5MM G
D712 C0072401 CC,B50V 1000PF K UP025 G
D812 C0072401
CC,B50V 1000PF K UP025 G
PCBA,T-GATHER B JPN AD-RW900 G
PCBA,T-GATHER B EUR AD-RW900 G
PCBA,T-GATHER B EX/T/C AD-RW900 G
D010 S0070750 DIODE,LT2A05 G
V
D011 S0070750
DIODE,LT2A05 G
V
D012 S0070750
DIODE,LT2A05 G
V
REF.NO. PARTS NO. DESCRIPTION . REMARKS
D013 S0070750
DIODE,LT2A05 G
V
D001 3S003540
DI,IN5404-M22 G
V
D002 3S003540
DI,IN5404-M22 G
V
D003 3S003540 DI,IN5404-M22 G
V
D004 3S003540 DI,IN5404-M22 G
V
D005 S0071811 DI,1N4003-F TAPINGW=52 G
V
D006 S0071811
DI,1N4003-F TAPINGW=52 G
V
D007 S0071811 DI,1N4003-F TAPINGW=52 G
V
D008 S0071811 DI,1N4003-F TAPINGW=52 G
V
D311 S0071811 DI,1N4003-F TAPINGW=52 G
D009 3S036301 DI,SCHOTTKY 60V2A D2S6M
D014 3S036301 DI,SCHOTTKY 60V2A D2S6M
F2 E0148702 CKT PTCT,1.35A RXEF135 TPG
V
F3 E0148702
CKT PTCT,1.35A RXEF135 TPG
V
F1 E0148702 CKT PTCT,1.35A RXEF135 TPG
V
F4 E0148702 CKT PTCT,1.35A RXEF135 TPG
V
U904 3S038924
IC,LC75348M G
U351 S0061754 @IC,HA12134AFEL-E G
U352 S0078210 IC,BU4066BC G
U906 S0078210 IC,BU4066BC G
U302 S0064550 IC,NJM4558D G
U353 S0064550 IC,NJM4558D G
U902 S0064550 IC,NJM4558D G
U903 S0064550 IC,NJM4558D G
U905 S0064550 IC,NJM4558D

G
U907 S0064550 IC,NJM4558D G
U908 S0064550
IC,NJM4558D G
U301 3S000280G IC, UPC4570C-A G
U909 3S000280G
IC, UPC4570C-A G
U002 S0075052 @IC,TA7807SB(TP,Q) G
V
U003 S0075072 @IC,TA79007SB(TP,Q) G
V
U004 S0082972 IC,BD9702CP-V5 G
V
U001 S0082972
IC,BD9702CP-V5 G
V
L302 3E003711G
COIL, 10UH EC24-100K-T2 G
L303 3E003711G COIL, 10UH EC24-100K-T2 G
L151 3E003690G COIL, #7159 8.2MH G
L251 3E003690G COIL, #7159 8.2MH G
L001 E0130740
COIL,10UH 3.6A DR2W8*7 G
L002 E0130740 COIL,10UH 3.6A DR2W8*7 G
U151 E01523300A @VAR COIL,MPX 079418007 G
U251 E01523300A @VAR COIL,MPX 079418007 G
L155 E01523300A @VAR COIL,MPX 079418007 G
L255 E01523300A
@VAR COIL,MPX 079418007 G
L156 E01523400A
@VAR COIL,MPX 079418008 G
L256 E01523400A
@VAR COIL,MPX 079418008 G
TP101 E0127550 PIN,TEST G
TP102 E0127550 PIN,TEST G
TP201 E0127550
PIN,TEST G
TP202 E0127550
PIN,TEST G
L301 E01431500A @TRANS,BIAS OSC 85KHZ G
J703 3E017520 JACK, RJ-1106A-09-03E1B G
J702 E0123140 JACK,RJ-1073B-09-0320A G
