TEAC AD-RW900/900E
- 47 -
CAUTION
Part with numbers in parentheses ( ) cannot be ordered. If you want to order service parts, be sure
to use "Child" part numbers (numbers in Bold), which refer to individual parts of a parent part.
注意
"( )"付き品番は、発注できません。補修部品を発注する際は、太字品番で発注してください。
REF.NO. PARTS NO. DESCRIPTION . REMARKS
3E95100152A PCBA,CPUERP2AD-RW900G
PCBA,S-CPU AD-RW900 G
LS1 E0081244
COIL,BLM18PG600SN1D G
LS2 E0081244 COIL,BLM18PG600SN1D G
LS3 E0081244 COIL,BLM18PG600SN1D G
L1 E0081244 COIL,BLM18PG600SN1D G
L2 E0081244 COIL,BLM18PG600SN1D G
V
L3 E0081244
COIL,BLM18PG600SN1D G
V
L4 E0081244 COIL,BLM18PG600SN1D G
L5 E0081244 COIL,BLM18PG600SN1D G
L6 E0081244 COIL,BLM18PG600SN1D G
L7 E0081244 COIL,BLM18PG600SN1D G
L8 E0081244 COIL,BLM18PG600SN1D G
L9 E0081244
COIL,BLM18PG600SN1D G
L10 E0081244 COIL,BLM18PG600SN1D G
L11 E0081244
COIL,BLM18PG600SN1D G
L12 E0081244 COIL,BLM18PG600SN1D G
L13 E0081244 COIL,BLM18PG600SN1D G
L20 E0081244
COIL,BLM18PG600SN1D G
L23 E0081244
COIL,BLM18PG600SN1D G
L201 E0081244 COIL,BLM18PG600SN1D G
L202 R0156404 RD,1/10W 100 OHM J0603G
L203 E0081244 COIL,BLM18PG600SN1D G
L19 C0074994 CC,X7R 16V 1.0UF K T0603G
U10 3S039984 IC,WM8731SEDSRV G
U1 3S039944 IC,TCC8601 QFP144-3 G
U17 3S039974 IC,SN74HC32PWR G
U3 S0095154 IC,D7029-2V9 G
U6 S0082443
IC,JMH330APC1-TGCC
U4 S0089163 @IC,M12L128168A-7T-G2T G
EM006 S0086044 ZENER DIO,CDZCT2R6.8B G
EM005 S0086044 ZENER DIO,CDZCT2R6.8B G
EM003 C0071804 CC,18V 3PF M EZJ G
EM004 C0071804
CC,18V 3PF M EZJ G
PCBA,T-CPU ERP2 AD-RW900 G
Y1 3E083620 XTAL,12MHZ 18PF HC49S G
Y3 3E083610 XTAL,25MHZ 18PF JU308 G
Y2 E0124762 XTAL,32.768K NC38(6.3PF)G
JS1 E0119750 CONNECTOR,B 4B-PH-K-S G
J6 E0170100 CONN,WATK-07A1L1BU3
J21 3E083580 PIN HEADER,27PIN-2210S27 G
J22 3E083570 PIN HEADER,24PIN-2210S24 G
J5 E0119740
CONNECTOR,B 3B-PH-K-S G
A0008800
CREAM SOLDER,S70G-SX
3E95100250A
PCBA,GATHER-AAD-RW900G
PCBA,S-GATHER A ERP2 AD-RW900 G
L401 E0081244 COIL,BLM18PG600SN1D G
L402 E0081244
COIL,BLM18PG600SN1D G
L405 E0081244
COIL,BLM18PG600SN1D G
L406 E0081244
COIL,BLM18PG600SN1D G
L403 E0081244 COIL,BLM18PG600SN1D G
Q408 S0041574 TRANSISTER,DTA124EUA G
Q410 S0041574
TRANSISTER,DTA124EUA G
Q401 S0065074
TRANSISTOR,DTC124EUA TP G
REF.NO. PARTS NO. DESCRIPTION . REMARKS
Q403 S0065074
TRANSISTOR,DTC124EUA TP G
Q405 S0065074
TRANSISTOR,DTC124EUA TP G
Q406 S0065074
TRANSISTOR,DTC124EUA TP G
Q407 S0065074 TRANSISTOR,DTC124EUA TP G
Q409 S0065074 TRANSISTOR,DTC124EUA TP G
Q411 S0065074 TRANSISTOR,DTC124EUA TP G
Q402 S0075364 TRANSISTER,2SB1188 G
Q404 S0075364
TRANSISTER,2SB1188 G
U404 3S039034 IC,SN74LVC14ADR G
U406 3S038914 IC,RT9702 GB G
U403 3S038834 IC,AMS1117-1.8 SOT-223 G
U402 3S039024 IC,D1117-3V3 G
U401 3S0400900A
IC,GC89L581A0 OR GC89L591A0 G
3S039954 IC,GC89L581A0 G
3S040084
IC,GC89L591A0 G
L551 E0081244 COIL,BLM18PG600SN1D G
L552 E0081244
COIL,BLM18PG600SN1D G
L553 E0081244
COIL,BLM18PG600SN1D G
L554 E0081244 COIL,BLM18PG600SN1D G
U501 S0059584 IC,AK4117VF G
U502 S0084354 IC,PCM2900BDBR G
L555 E0081244 COIL,BLM18PG600SN1D G
L556 E0166304 FILTER,NT2012 985BH1007 G
EM001 C0071804 CC,18V 3PF M EZJ G
EM002 C0071804 CC,18V 3PF M EZJ G
JMP3 R0157394 RD,1/10W 0 OHM J0603G
JMP4 R0157394
RD,1/10W 0 OHM J0603G
JMP5 R0157394 RD,1/10W 0 OHM J0603G
Q504 S0065074
TRANSISTOR,DTC124EUA TP G
J903 E0101924 CONNECTOR,B 3B-PH-SM4(LF)
PCBA.A-GATHER A AD-RW900 G
D571 3S002041
@ZDI,MTZJ3.3B T-77
PCBA,T-GATHER A AD-RW900 G
S501 E0127100 SW,TACT SKHHAM2520 G
S502 E0127100 SW,TACT SKHHAM2520 G
S503 E0127100 SW,TACT SKHHAM2520 G
S504 E0127100
SW,TACT SKHHAM2520 G
S505 E0127100 SW,TACT SKHHAM2520 G
S506 E0127100 SW,TACT SKHHAM2520 G
S507 E0127100 SW,TACT SKHHAM2520 G
S508 E0127100 SW,TACT SKHHAM2520 G
S512 E0127100
SW,TACT SKHHAM2520 G
S513 E0127100
SW,TACT SKHHAM2520 G
S514 E0127100
SW,TACT SKHHAM2520 G
S515 E0127100 SW,TACT SKHHAM2520 G
S516 E0127100 SW,TACT SKHHAM2520 G
S517 E0127100 SW,TACT SKHHAM2520 G
S518 E0127100
SW,TACT SKHHAM2520 G
S519 E0127100
SW,TACT SKHHAM2520 G
S523 E0127100
SW,TACT SKHHAM2520 G
S524 E0127100 SW,TACT SKHHAM2520 G
S525 E0127100 SW,TACT SKHHAM2520 G
S526 E0127100 SW,TACT SKHHAM2520 G
S527 E0127100
SW,TACT SKHHAM2520 G
S528 E0127100
SW,TACT SKHHAM2520 G
PCB GATHER,CPU AD-RW900 G / PCB,GATHER-A AD-RW900 G

