Example: Connection to Video Cassette Recorders
Exemple: Raccordement à un magnétoscope
Ejemplo: Conexión de grabadoras de cintas de vídeo
S-VIDEO OUT S-VIDEO IN
LINE OUT
L
R
LINE
OUT
LINE
IN
LL
RR
S-VIDEO
OUT
S-VIDEO
IN
TV (MONITOR)
VCR (VIDEO 2)
VCR (VIDEO 1)
