ENGLISH
Basic Operation 1
50
Press the POWER switch.
The unit enters standby mode, and the standby indicator lights.
Press the STANDBY/ON switch to turn the unit on.
The power indicator lights, and the standby indicator goes off.
Select a source by turning the FUNCTION knob (or pressing
one of the FUNCTION buttons of the remote control unit).
The selected source is shown on the front panel's display.
<
If one of the FUNCTION buttons or 7CH DIRECT button of the
remote control unit is pressed in the standby mode, the unit is
turned on with the selected source automatically.
<
If the source is connected to 7CH DIRECT INPUT jacks, press
the 7CH DIRECT button and proceed to step .
When you selected VIDEO(1, 2 or 3) or CD in step , press the
DIGITAL INPUTS button repeatedly to select the terminal.
c1:
Select this when the source is connected to DIGITAL IN
(COAXIAL 1) terminal.
c2: Select this when the source is connected to DIGITAL IN
(COAXIAL 2) terminal.
o1: Select this when the source is connected to DIGITAL IN
(OPTICAL 1) terminal.
o2: Select this when the source is connected to DIGITAL IN
(OPTICAL 2) terminal.
A: Select this when the source is connected to analog AUDIO
IN jacks.
<
DIGITAL indicator blinks when the unit cannot perceive the
digital signal. In that case, connect a digital device to the
DIGITAL IN terminal, switch it on, and select the terminal by
pressing the DIGITAL INPUTS button.
<
You can hear the sound from the selected DIGITAL IN terminal
as far as VIDEO(1,2 or 3) or CD has been selected in step .
Play the source, and gradually turn up the volume to the
required level by turning the VOLUME knob.
5
3
34
5
3
2
1
Recording a Source
1. Select a source to be recorded by turning the FUNCTION knob
(or pressing one of the FUNCTION buttons of the remote
control unit).
2. Start recording.
<
The volume and tone control have no effect on the recording
signals.
<
The analog signals input from the 7 CH DIRECT INPUT jacks
cannot be recorded.
To Next Page
