Teac AG-D8800 - AMP PCB SUB ASSY; POWER PCB SUB ASSY

AMP PCB SUB ASSY
REF. NO
REMARKS
PARTS NO.
DESCRIPTION
L201C,201L,201R
D330900001330
FILTER INDUCTOR - SP-2507
K000013300520
DIODE - 1SS133T
JACK301
G606040320020
TER RCA 3PIN
CP201
L101220100000
CN WAFER 2MM 10PIN
7028062221010
AMP PCB SUB ASSY
7020062220000
AMP PCB
D202C,202L,202R,
Q201C,201L,201R,
J5000992F0050
TR - KSA992F
D202SR,202SL,
D203C,203L,203R,
D203SL,203SR
Q201SL,201SR,
Q202C,202L,202R,
Q202SL,202SR,203C
Q203L,203R,203SL,
Q203SR,204C,204L,
Q204R,204SL,204SR,
Q207C,207L,207R,
Q207SL,207SR
Q208C,208L,208R,
Q208SL,208SR
J5001024Y0050
TR - KTA1024Y
Q205C,205L,205R,
Q205SL,205SR,
Q206C,206L,206R,
Q206SL,206SR,
Q215C,215L,215R,
Q215SL,215SR
J5021845F0000
TR - KSC1845F
Q209C,209L,209L,
Q209SL,209SR
J5023206Y0050
TR - KTC3206Y
POWER PCB SUB ASSY
70280600910V0
POWER PCB SUB ASSY
REF. NO
REMARKS
PARTS NO.
DESCRIPTION
7020060090004
POWER PCB
L710
D330100700520
FILTER INDUCTOR - 10UH
D714-717
K000013300520
DIODE - 1SS133T
D710-713
K000400700520
DIODE - 1N4007
ZD715
K06004R344520
ZENER DIODE MTZJ 4.3B 1/2W
ZD711
K06007R544520
ZENER DIODE MTZJ 7.5B 1/2W
ZD712,713
K06015R044520
ZENER DIODE MTZJ 15B 1/2W
T710
8200280150260S
POWER TRANSFORMER
RY710
G680090102010
RELAY G5P-1 DC9V
IC710
J126780600190
IC - CJ7806
CP714
L101220080000
CN WAFER 2MM 8PIN
CP710
L102526700400
CN WAFER 2.5MM 4PIN
CP711,713
L1043532803200
CN WAFER 3.96MM 2PIN
CP712
L108039602010
CN WAFER 7.92MM 2PIN
F711
N751222501110
FUSE GLASS T2.5A/250V
F712
N751224001110
FUSE GLASS T4A/250V
!
!
!
AG-D8800
13
G435040110000
POWER SOCKET
Q711
J6020107M0010
TR - KRC107M
Q712
J5000916Y0050
TR - KSA916Y
