Teac AG-D8800 - DSP PCB SUB ASSY

DSP PCB SUB ASSY
REF. NO
REMARKS
PARTS NO.
DESCRIPTION
E100116500040S
CP803
L101220140010
CN WAFER 2MM 14PIN
IC809
CN WAFER 2MM 4PIN
L801,804
D3304R7000150
FILTER INDUCTOR - 4.7UH
L802,803
D3302R2000150
FILER INDUCTOR - 2.2UH
MODULE-JSR1165-C
7028062181050
DSP PCB SUB ASSY
7020062180001
DSP PCB
J126780500430
IC - CJ7805
CP802
XTAL801
E80012R288080
CRYSTAL 12.288MHZ
Q804C,804FL,
J502287400010
TR - KTC2874B
Q804FR,804SL
Q804SR,804SW
Q805FL,805FR
J5441170Y0050
CB801-806
COIL BEAD CHIP HB-IT2012-121JT
IC802
J040740400260
IC - 74VHCU04
IC806
J040742440160
IC - MM74HCT244WMX
IC805
IC808
J040742440170
IC - MM74HC244WMX
IC801
L101220040010
CP801
L101220150010
CN WAFER 2MM 15PIN
FET - 2SK117Y
7611010000020
J080458600010
IC - AK4586VQ
IC803
J080493260020
IC - CS493264-CL
IC810-815
J121455800150
IC - CJ4558CP
IC804
J126111725020
IC - RC1117-2.5
IC807
J126111733020
IC - RC1117-3.3
Q801,803,806
J5200107S0050
TR. CHIP - KRA107S
Q802,807
J522107S00210
TR. CHIP - KRC107S
D801-803,805FL,
D805FR
K005041480020
DIODE CHIP - 1N4148W
AG-D8800
15
JK801
G601020009100
TER, RCA 2PIN
