Connection
CAUTION
Turn off the power of all the equipment before making connections.
Read instructions of each component you intend to use with this unit.
Be sure to insert each plug securely. To prevent hum and noise, do not bundle the connection
cords with the power cord.
G
)R(
re
kaep
)SL(
r
ekaep
S
Rear panel of the main unit
TV (monitor)
Subwoofer
DC IN
Connect the "DC OUT" calbe of the
subwoofer to the "DC IN12V" jack.
After connecting the connection, attach
the connection cover to avoid the
connection coming out.
Side panel of the main unit
ANTENNA
FM/DAB
