Teac LEV3294HD - Stand Assembly Guide; TV and Stand Parts List; Stand Installation Steps; Stand Assembly Warnings

6
CAUTION:
1. All parts must be positioned correctly and all screws must be fixed tightly. Otherwise, the TV
may become unstable and could tip over to cause damage and injury.
2. Do not force the TV to turn to the side more than the stand allows. Do not tilt the screen up
or down. Doing so may damage the stand and cause the TV to become unstable.
1. TV and stand parts
2. Installing the stand
3. Warnings
First of all, please check that you have all of the parts and that there is
no visible damage. If a part is missing or appears damaged, please
contact the TEAC Customer Service Hotline at 1300 553 315.
Put the TV face down on a soft and flat surface (blanket, foam etc.) to prevent damage and scratching to the TV.
Side view
TV set
Stand
Put the neck onto the back of the TV set as shown below, and attach the neck with the supplied screws (5xST4X12F,
2xST4X16F
).
Basic OperationOSD Menu
Multimedia Operation
Recording
Operation
User Guidance Information
Maintenance and Service
DVD Operation
Screws(supplied)
Neck
Put the stand to the neck of the TV set as shown below, and attach the neck with the supplied screws (5xST4x16F).
When attaching, make sure the screws are attached tightly.
If the screws do not attach tightly, it will lead the TV to be unstable or
may even tip over.
1. Before you put on the stand, please make sure the direction is correct
as shown below.
2. When you are putting on the stand, please make sure the neck of the
TV set is in the correct position and attached tightly.
3. When attaching the stand, make sure the screws are attached tightly.
NOTE: If you do not attach correctly and tightly, it will make the TV
unstable and may tip over.
5 x ST4 x 16F
5 x ST4 x 12F
2 x ST4 x 16F
5 x ST4 x 12F
2 x ST4 x 16F
5 x ST4 x 16F
Back
Front
Front
