Teac LPU190 - Turntable Parts


8
Turntable Parts
Part Description
A. Turntable Platter Holds and rotates vinyl records.
B. 45 RPM Adaptor Use this adaptor when playing a 45 RPM record.
C. Tone arm Control
Indicator
The indicator lights up when the tone arm is in us
e.
D. Decoration Do not use this for tone arm adjustment.
E. Tone arm
Holds the stylus. Move the tone arm over a record on the platter to
place the stylus for music playback.
F. Tone arm Rest
Place the tone arm back on the tone arm rest after stopping
playback.
G. Speed Selector Select the appropriate speed for the current record before playing.
H. Stylus
Reads the record’s grooves when the record is spinning on the
platter.
I. Stylus Cover Protects the stylus when not in use.
