tecan NanoQuant Plate - Page 20

20 Quick Guide NanoQuant Plate
TM
No.30035094 Rev No. 1.4 2013-06
Typical performance values Infinite 200 PRO
Wavelength absorbance
Wavelength accuracy < ± 0.5 nm for λ > 315 nm
< ± 0.3 nm for λ ≤ 315 nm
Wavelength reproducibility < ± 0.5 nm for λ > 315 nm
< ± 0.3 nm for λ ≤ 315 nm
Absorbance bandwidth Infinite M200 PRO < 5 nm for λ ≤ 315 nm
< 9 nm for λ > 315 nm
Absorbance bandwidth Infinite F200 PRO Depending on filters used
Measurement absorbance
Detection limit (DNA concentration) 1 ng/μl dsDNA
Reproducibility of one sample (50 μg/ml) < 1 % CV
Ratio 260/280 (50 μg/ml) ± 0.07
Precision @ 260 nm < 0.2 %
Accuracy @ 260 nm < 0.5 %
Figure 13: Technical drawing of the NanoQuant Plate (dimensions in mm)
