34Technetix Group LimitedRev.1._0.1_0217
Connect USB cable to digital control module and
configure settings using the DBx software. All
settings for the optical module can be executed
with the same configuration as a RF amplifier
The incoming fibre needs to be inserted into
the amplifier through the lid port (5/8th thread).
Ensure the cable is securely fitted inside clips.
Close DBx product, ensuring all bolts are secured
correctly. The upgrade of the amplifier to an
optical fibre node is now completed.
05
04
06
10
min
8
min
4
min
