35 Technetix Group Limited Rev.1._0.1_0217
5.7 Optical modules
The platform has the following main modules for a default node applications:
DBRX-A-1 1.2GHz optical receiver module
DBTX-A-1 204MHz dual optical transmitter module
DBLB-31-3D-1 Plug-in laser board 1310nm 3dBm analogue
DBLB-55-3D-1 Plug-in laser board 1550nm 3dBm analogue
DBLB-cxx-3D-1 Plug-in laser board CWDM wavelength selection 3dBm analogue
DBLB-CB-1 Combining board for hybrid RF/node configuration which combines upstream over signal laser.
DBLB-BP-1 Terminating board in case of a single upstream in a DBC for the 2nd slot in DBTX-A-1
DBLB-TP-CON MCX to F-Female adapter for measuring upstream RF level
Other output power options are available, please contact your local sales representative for further information.
details available technetix.com
