100/1000BASE-T1 MediaConverter MATEnetUser Manual
16
3.2 Configuration through Power MQS Connector
The PINs 2, 3, and 4 of the Power
MQS connector (CHAPTER 2.1.3) can be used for
configuration and link status output.
3.2.1 Link Status Output (LS) (PIN 2)
The Link Status PIN 2 outputs a weak 3.3 Volts status signal. There is an integrated
5K Ohm pull-up resistor to 3.3 Volts. This PIN is active high. The pull-down transistor
can drain up to 100mA.
3.2.2 Force Link Down (LD) (PIN 3)
If you connect PIN 3 and PIN 1 by a shortcut wire link down is forced. These pins are
active low. There is an integrated 5K Ohm Pullup to 3.3 Volts. For normal operation
please disconnect the PINs.
While removing the shortcut of PIN 3 and PIN 1, a full reset of the device will be
done.
3.2.3 Force Slave mode (FS) (PIN 4)
If you connect PIN 4 and PIN 1 by a shortcut wire Force Slave mode is activated.
These pins are active low. There is an integrated 5K Ohm Pullup to 3.3 Volts.
For normal operation please disconnect the PINs.
Activated Force Slave mode overrides the DIP switch configuration.
Force Slave mode must be applied before powering up. Otherwise, a power reset
is needed.
