3.3 Frame Generator
The 100/1000BASE-T1 MediaConverter in frame generator mode is working only on
the BASE-T1 port as a frame generator. The generated frame is in total 1514 bytes long
and is sent with
Roundabout 12 Mbps in 100BASE-T1 mode
Roundabout 120 Mbps in 1000BASE-T1 mode
The frame contains no specific MAC source or destination. All bytes have the same
pattern: 0xA5 and 0x5A in alternation.
Figure 3-1: Frame by Frame Generator
