14
1GETTING START
ED
DMS-CTC-20110713-0016 v2.0
Broadband LED (if you are using the Local Router scenario)
Internet LED
Phone LED
DECT LED
WPS LED
For more information about WPS, see “5.1 Connecting Your Wireless Client via WPS” on page 44.
Colour State Description
Green Solid on Connected to the WAN device
Off Not connected to the WAN device or the status LEDs are deactivated
Colour State Description
Green Solid on Connected to the Internet, no activity
Blinking Connected to the Internet, sending/receiving data
Red Solid on Failed to setup the Internet connection
Off No Internet connection or the status LEDs are deactivated
Colour State Description
Green Solid on Registered at your VoIP provider, no activity.
Blinking Registered at your VoIP provider, activity.
Off Not registered to your VoIP provider or the status LEDs are deactivated.
Colour State Description
Green Solid on DECT service up
Blinking DECT activity or registering DECT clients
Off DECT service down or the status LEDs are deactivated
Colour State Description
Green Solid On Client successfully registered via WPS
Orange Blinking WPS registration ongoing
Red Blinking Error occurred
