Technics RS-646DS-D

Part Name & Description
TRANSFORMERS
Remarks
RS-646DS-D
QLT2D10A
Headphone Transformer
QLBTO111
Oscillator Transformer
Part Name & Description
ELECTRICAL PARTS
Remarks
RS-646DS-D
WY436AD
Record/Playback Head
QWwY2118
Erase Head
COILS
QLM9Z002W
Low Pass Filter
Coil
QSL4006RNM
QSL4007RNM
i Level Meter (Battery Indicator)
"
EAS10P101S
Speaker
QMK1610
Front Chassis
Jack Board Angle
QLQX2421Y
QLH2008
Choke Coil
QLQX2421Y
Coil
SWITCHES
QSS7203
Slide Switch
(Record/Playback Selector)
QST4305T
Lever Switch (LINE/MIC Selector)
RQ-548S
QST4210T Lever Switch (Equalizer Selector)
QST2215T
Lever Switch
(Limiter, Dolby Selector)
QSw2202
QST2215T
Push Switch (Battery Check)
Lever Switch (Bias Selector)
Qsw2202 Push Switch (Meter Light)
QSBO169M1
Leaf Switch (Motor ON/OFF)
RS-640US
QSM0037
Micro Switch (Motor ON/OFF)
RS-276US
Refer to VR603
Speaker ON/OFF Switch
QSBO169M1
Leaf Switch
RS-640US
QSS2209T
Muting Switch
”
JACKS
Refer to E8
LINE IN/LINE OUT/DIN Jacks
(Interlocked with Jack Board)
QJAG252H
Headphone Jacks
QJA0248
Microphone Jacks
RS-671AUS
PILOT LAMPS
XAMQ23P200N
Pilot Lamp
QMA2969
QEJ5004S
Jack Board Assembly
QMA2973
Jack Angle
QTW1142
Isolation Sheet for Mic Jack
4:3 See
QTS1390
Mic Jack Shield Plate
QNQ1051
Mic Jack Nut
QBH2015
Shelter for Lever Switch
QMA2972
LED Angle
QBG1562
| Rubber Bushing
QNQ1004
VR Nut
QWQ2002
QXH0246
L Spring Washer
| VR Shaft Holding Bass Assembly
QDG1099
VR Gear (B)
QDG1100
VR Gear (C)
QDG1098
| VR Gear (A)
QBC8006A
Pressure Spring for Gear
QMS2420A
Shaft
QDG1101
VR Gear (D)
XUC3FT
Stop Ring
COMMON
QBW2019
Poly Washer
”
QBK7005
Fiber Washer RS-9900US
QBw2018 Poly Washer
COMMON
QBK7017 Fiber Washer RS-466S
QMA2971 Meter Holding Plate
QBG1395
Meter Lamp Cover
RS-640US
QBJ3122
QBJ3149
Washer for Headphone Jack
”
