31 SP A O Speaker A control output
32 AF MUTE O Muting control output
33~48 SEG16~SEG1 O FL segment signal output
49~58 DEG1~DEG10 O FL digit signal output
59 INIT_IN I Diode input initial settings
60 VOL DOWN O Volume control output (Down)
61 VOL UP O Volume control output (Up)
62 VIDEO_C - Not used
63 IF DATA I Serial data signal
64 LIMMITER O Power limitter control output
65 T CE O Tuner control (CE) chip enable signal
66 T CK O Selector/Tuner (CK) clock signal
67 T DT O Selector/Tuner (DT) data signal
68 PRT_VCC2 I Encoder of surround mode selector input1
69 MMD_CTR I Encoder of surround mode selector input1
70 COM CK O Common clock signal
71 COM DO O Common digital output signal
72 COM DI I Common digital input signal
73 AVSS - GND for A-D converter
74 VREF - Reference voltage for A-D converter
75 SD I SD signal detect input
76 COM REQS O Common serial request output
77 HELP LED/RDS CE O Help LED control output (Not used, open)
78 COM REQM O Common mechanical request output
79 VIDEO B O Video selector control output B
80 VIDEO A O Video selector control output A
•@
