Caution!
IC, LSI and VLSI are sensitive to static electricity.
Secondary trouble can be prevented by taking care during repair.
Cover the parts boxes made of plastics with aluminium foil.
Put a conductive mat on the work table.
Ground the soldering iron.
Do not touch the pins of IC, LSI or VLSI with fingers directly.
file:///C|/Documents%20and%20Settings/Administrateur/Mes%20documents/service/SA-DA10/p18.htm (2 of 3) [21/01/2007 13:47:13]
