13.2 Electrical Parts List
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name& Description Remarks
P.C.B.
REP3019A-M POWER AMP P.C.B./MAIN P.C.B./TRANSFORMER P.C.B. [M]RTL
REP3020A-S FRONT VCR3 INPUT P.C.B./S-VIDEO P.C.B./HEADPHONES P.C.B./PHONO P.C.B./LED1
P.C.B./LED2 P.C.B./EARTH TERMINAL P.C.B./PANEL P.C.B./TONE P.C.B./KEY P.C.B.
[M]RTL
REP3021A-P SURROUND P.C.B./INPUT SELECTOR P.C.B./VOLUME P.C.B./POWER P.C.B./SPEAKER
TERMINAL P.C.B./AC IN/OUT P.C.B.
[M]RTL
RAN0001MM TUNER MODULE P.C.B. [M]RTL
REP2730E-T DTS MODULE P.C.B. [M]RTL
INTEGRATED CIRCUITS
IC301 NJM2279D IC VIDEO SELECTOR SW [M]
IC302 NJM2279D IC VIDEO SELECTOR SW [M]
IC351 NJM2296D IC VIDEO SELECTOR [M]
IC401 TC9163AN IC SELECTOR [M]
IC402 NJM4580EDTE1 IC OP AMP [M]
IC403 TC9162AN IC SELECTOR [M]
IC404 NJM4580EDTE1 IC OP AMP [M]
IC405 NJM4580EDTE1 IC OP AMP [M]
IC406 NJM4580EDTE1 IC OP AMP [M]
IC451 AN6558F IC OP AMP [M]
IC501 BA6218 IC MOTOR DRIVER [M]
IC502 NJM4580EDTE1 IC OP AMP [M]
IC503 NJM4580EDTE1 IC OP AMP [M]
IC504 NJM4580EDTE1 IC OP AMP [M]
IC505 NJM4580DD IC OP AMP [M]
IC506 NJM4580DD IC OP AMP [M]
IC507 NJM4580DD IC OP AMP [M]
IC508 NJM4580DD IC OP AMP [M]
IC601 RSN313H25-P IC HIC
[M]
