S909:
6 ch discrete input switch / (6 CH DISCRETE INIPUT)
S910:
Tuning down switch (TUNING, )
S911:
Tuning up switch (TUNING, )
S912:
Tuner/band switch (TUNER/BAND)
S913:
Digital super woofer switch / (DIGITAL S.WOOFER)
S914:
RDS display mode PS switch / (RDS DISP MODE-PS)
S915:
RDS display mode PTY switch / (RDS DISP MODE-PTY)
VR901:
Volume control VR (VOLUME)
- Indicated voltage values are the standard values for the unit
measured by the DC electronic circuit tester (high-impedance)
with the chassis taken as standard. Therefore, there may exist
some errors in the voltage values, depending on
theinternalimpedance of the DC circuit tester.
No mark
: Power ON (FM or AM)
- Important safety notice:
Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of components, be sure to use only
manufacturer´s specified parts shown in the parts list.
- The supply part number is described alone in the replacement
17
