parts list.
- Voltage and signal line
: Positive voltage line
: Negative voltage line
: Audio signal line
: Tuner signal line
Caution!
IC and LSI are sensitive to static electricity.
Secondary trouble can be prevented by taking care during repair.
Cover the parts boxes made of plastics with aluminum foil.
Ground the soldering iron.
Put a conductive mat on the work table.
Do not touch the legs of IC or LSI with the fingers directly.
10. Schematic Diagram
11. Printed Circuit Board Diagram
12. Type Illustration of ICs, Transistors and Diodes
13. Wiring Connection Diagram
14. Block Diagram
15. Terminal Function of ICs
15.1. IC901 (C2BBFD000404): / System Control/FL Drive
