The optical pickup and the magnetic head are structured precisely; therefore, they
are very fragile. Be careful not to touch them with the edge of the laser power
meter.
-
The sensor of the laser power meter is a very fine part. Be careful not to touch it to
the optical pickup lens.
-
The focus point of the laser reaches to 356°F. Therefore, avoid adjusting using
laser power for a long time because the sensor of the laser power meter may be
burned.
-
Do not allow the write power to even momentarily reach or exceed 5.5 mW. Doing
so will result in damage to the optical pickup.
-
Do not set the unit to the laser power adjustment mode with the MD loaded. Doing
so may result in damage to the MD.
9.3. Adjustment Procedure
Note:
There are two methods of adjusting the player, either by using a laser power meter or
by using a cartridge type laser power meter.
1. EntertheAdjustmentMode.
2. If using a laser power meter, slide open the sensor cover. (Refer to
Fig.9.)
Fig.9
3. If using a laser power meter, position the sensor directly above the optical pickup.
(Refer to
Fig.10.)
If using a cartridge type laser power meter, load the cartridge into the MD
22
