Pin
No.
Mark I/O
Division
Function
97 AVSS — GND terminal
98 P100/
AN0
— Not used, connected to
GND
99 VREF I Referance voltage input
terminal
100 AVCC I Power supply input
terminal
17. Replacement Parts List
Notes:
*Important safety notice:
Components identified by
mark have special characteristics important for safety.
Funrthermore, special parts which have purposes of fire-retardant (resistors),
high-quality sound (capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufacture’s specified
parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution statements.
*ACHTUNG:Die lasereinheit nicht zerlegen.Die lasereinheit darf nur gegen einc vom
hersteller spezifizierte einheit ausgetauscht werden.
*Capacity values are in microfarads (uF) unless specified otherwise, P=Pico-farads
(pF) F=Farads (F)
*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM),
1M=1,000K (OHM)
*[MAVD] indicates in Remarks colums parts that are supplied by MAVD.
*The marking <RTL> indicates that the Retention Time is limited for this item. After
the discontinuation of this assembly in production, the item will continue to be
available for a specific period of time. The retention period of availability is
dependant on the type of assembly , and in accordance with the laws governing part
and product retention. After the end of this period, the assembly will no longer be
available.
*“<IA>”, “<IB>”, “<IC>”, marks in Remarks indicate languages of instruction
manuals. [<IA> : English, <IB> : German / Italian / French, <IC> : Netherlands / Danish
/ Spanish / Swedish / Polish]
53
