Technics SJ-HD501

Ref. No.
Part No.
Part Name & Description Pcs Remarks
1 RGK1148-M
SIDE PANEL(L)
1
2 RGK1149-M SIDE PANEL(R) 1
3 RHD30073-K SCREW 4
4 RKM0326G-S CABINET 1 [MAVD]
5 XTBS3+8JFZ1 SCREW 1
6 REZ1250 FFC(30P) 1 [MAVD]
7 REZ1251 FFC(20P) 1 [MAVD]
8 RKA0076-N3 FOOT 4
8-1 RKA0083-K CUSHION 4
9 XTB3+6G SCREW 4
10 RGK0810-N3 SIDE ORNAMENT(L) 1
11 RGK0811-N3 SIDE ORNAMENT(R) 1
12 RGK0886-1H MD LID 1
13 RGL0345-Q LED INDICATOR 1
14 RGG0139C-S FRONT PANEL 1 [MAVD]
15 RGL0455-Q INDICATOR 1 [MAVD]
16 RGP0573A-S1 SUB PANEL 1 [MAVD]
17 RGU1471A-S BUTTON POWER 1 [MAVD]
18 RGU1472-S BUTTON PLAY 1
19 RGU1473-S BUTTON ENTER 1
20 RGU1474A-S BUTTON DISPLAY MODE 1 [MAVD]
21 RGU1475-S BUTTON EJECT 1
22 RGW0254-S KNOB JOG 1
23 RHD20010 SCREW 2
24 RHD26021 SCREW 5
25 RHN70002 NUT 1
26 RKW0482A-Y FL WINDOW 1
27 RKW0483-Q REMOTE SENSOR WINDOW 1
28 RMB0495 SPRING 1
29 RMG0387A-K RUBBER 1
30 XTBR3+20JFZ SCREW 2
31 XTBS3+8JFZ1 SCREW 12
100 RED0047-1 MAGNETIC HEAD 1
101 RHD17021 SCREW 1
102 RHD17022 SCREW 1
103 RMC0348 THRUST SPRING 1
104 RMC0349 NUT PLATE SPRING 1
105 RML0515 HEAD SIFTER 1
106 RMQ0750 REF BASE 1
107 RMQ0751 NUT PLATE 1
108 RMS0611 MAIN SHAFT 1
109 RXJ0021 DRIVE SHAFT 1
110 RXK0249 MECHANISM CHASSIS 1
110-1 RDV0055 BELT 1
110-2 REM0077 TRAVERSE MOTOR 1
110-3 REM0078 LOADING MOTOR 1
110-4 RMB0548 PRESSURE SPRING 1
110-5 RMQ0752 DETECTOR PIN(1) 1
110-6 RMQ0753 DETECTOR PIN(2) 2
110-7 XQN17+C25FZ SCREW 6
110-8 XYC2+FF105 SCREW 1
111 RAF1700A OPTICAL PICKUP 1
112 XTW2+6S SCREW 1
113 RHD20053 SCREW 4
114 RMB0504 SPRING 4
115 RMG0447-K DAMPER 4
