VR1: Laser power adj. V.R..
-
VR901 : Input level/Jog push set V.R..
-
Indicated voltage values are the standard values for the unit measured by the DC
electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the
internal impedance of the DC circuit tester.
No mark: MD STOP
( ): MD play [1kHz, L+R, 0dB]
<>: MD rec. [1kHz, L+R, 0dB]
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthermore, special parts which have purpose of fire-retardant (resistors),
high-quality sound (capacitors), low-noise (resistors), etc. are used. When replacing
any of components, be sure to use only manufacture's specified parts shown in the
parts list.
Caution!
IC and LSI are sensitive to static electricity.
Secondary trouble can be prevented by taking care during repair.
Cover the parts boxes made of plastics with aluminum foil.
Ground the soldering iron.
Put a conductive mat on the work table.
Do not touch the legs of IC or LSI with the fingers directly.
Voltage and signal lines
: Positive voltage line
: Playback signal
: Recording signal
11.2. Type Illustration of IC's, Transistors and Diodes
