Technics SJ-HD501

Ref. No.
Part No.
Part Name & Description Pcs Remarks
L9-12 RLQU100KT-W COIL 4
L13,14 RLQU2R2MT-W COIL 2
L15 RLQU100KT-W COIL 1
L16 RLQU2R2MT-W COIL 1
L17,18 RLQP1R8KT2-Y COIL 2
L201,02 SLQX400-D COIL 2
P1 RPF0139 PROTECTION BAG(F.B.) 1
P2 RPG4525 PACKING CASE 1 [MAVD]
P3 RPN1008 CUSHION 1
P4 RPQ0981 PAD 1 [MAVD]
PCB1 REP2878AB-S POWER P.C.B. 1 <RTL>[MAVD]
PCB2 REP2878AA-S MAIN P.C.B. 1 <RTL>[MAVD]
PCB3 REP2878AC-S OPERATION P.C.B. 1 <RTL>[MAVD]
PCB4 REP2761A-T MD SERVO P.C.B. 1 <RTL>
Q1 2SB1295-6-TB TRANSISTOR 1
Q2 DTC114YETL TRANSISTOR 1
Q3 2SB1462STX TRANSISTOR 1
Q5 2SB1295-6-TB TRANSISTOR 1
Q6 DTC114YETL TRANSISTOR 1
Q10 2SJ278MYTR TRANSISTOR 1
Q11 2SK1764KYTR TRANSISTOR 1
Q13 2SB1121ST-TD TRANSISTOR 1
Q301,02
2SD1450S
TRANSISTOR
2
Q303 2SA1048GR TRANSISTOR 1
Q304 DTA114EUT106 TRANSISTOR 1
Q305 2SD1862QRTV6 TRANSISTOR 1
Q306 2SB1240-P TRANSISTOR 1
Q307 2SD1862QRTV6 TRANSISTOR 1
Q308 2SD2037EFTA TRANSISTOR 1
Q309 DTA114EUT106 TRANSISTOR 1
Q310 DTC114EUT106 TRANSISTOR 1
Q451,52 DTC114EUT106 TRANSISTOR 2
Q453 DTA114EUT106 TRANSISTOR 1
Q454,55 DTA143EUT106 TRANSISTOR 2
Q456 DTC114EUT106 TRANSISTOR 1
Q703-06 2SD1328QRSTX TRANSISTOR 4
Q901 DTA114EUT106 TRANSISTOR 1
Q902-05 DTC114EUT106 TRANSISTOR 4
Q906,07 DTA114EUT106 TRANSISTOR 2
Q913 DTC114EUT106 TRANSISTOR 1
R1 ERJ3GEYJ472V 1/16W 4.7K 1
R2 ERJ3GEYJ102Z 1/16W 1K 1
R3 ERJ3GEYJ472V 1/16W 4.7K 1
R5 ERJ3GEYJ1R0V 1/16W 1 1
60
