Technics SL-1200G User Manual

English
(14)
Connecting to an integrated amplifier or component system
Connections and installation

Turn off all units and disconnect the AC mains lead from the socket before making any
connections.

Connect the AC mains lead only after all other connections are completed.

Be sure to connect the PHONO earth lead. Otherwise mains hum may occur.

Refer also to the instruction manual of the connected device.
1
Connect the PHONO cables and
PHONO earth lead to the PHONO
terminals of the connected
equipment.

You will not have adequate volume or
sound quality if the connected amplifier
has no PHONO terminals.
2
Connect the AC mains lead.

Confirm the wattage of the AC outlet on
the connected equipment before using it
for this unit.
(This unit consumes 14 W.)

The operation switch does not separate entire unit from mains even if in “OFF“ position.
Remove the plug from the mains socket if you will not be using the unit for an extended period of
time. Place the unit so that the plug can be easily removed.
Note
Amplifier(not included)
PHONOPHONO
EARTH
Back of main unit
5V2.1APHONES
VOLUME
INPUTSELECTOR
LR
LR
Insert the AC mains lead
up to a point just before
the round hole.
PHONOcable
PHONO earth lead
To a household
mains socket
14

Technics SL-1200G Specifications

General

Drive Method	Direct Drive
Type	Manual Turntable
Motor	Coreless Direct Drive Motor
Tonearm Effective Length	230 mm
Tonearm Overhang	15 mm
Rumble	78 dB (IEC 98A Weighted)
Turntable Platter	Aluminum Die-cast
Wow and Flutter	0.025% WRMS
Tonearm Type	Static Balance
Cartridge Weight Range	5.6g to 12.0g (without auxiliary weight)
Speed	33 1/3 RPM, 45 RPM, 78 RPM
Dimensions	453 x 173 x 372 mm
Weight	18 kg
Power Supply	AC 120V, 60Hz
