Technics SL-1200G User Manual

English
(20)
Playing records
1
Turn [ON/OFF] to turn the unit on.
The strobe light comes on. 33-1/3 rpm is
automatically selected and the indicator [33]
lights.
2
Press [START-STOP].
The turntable starts revolving.
Speed select buttons
Indicators
·
4
3
5
1
2
EP record adaptor
Centre spindle

1

2

2
Preparation

1 Put a record on the turntable.

2 Take off the stylus cover and release the arm clamp.
ピピ フブ
ヘベ
ヴヵモンヵ〔ヴヵヰヱ
ピピ
ɿ
ɿ
ɿ
ヌプハフ
チ
チピハピ
チチ
パ
ノ
チ
ピハピ
テ
Strobe light
Indicator
20

Technics SL-1200G Specifications

General

Drive Method	Direct Drive
Type	Manual Turntable
Motor	Coreless Direct Drive Motor
Tonearm Effective Length	230 mm
Tonearm Overhang	15 mm
Rumble	78 dB (IEC 98A Weighted)
Turntable Platter	Aluminum Die-cast
Wow and Flutter	0.025% WRMS
Tonearm Type	Static Balance
Cartridge Weight Range	5.6g to 12.0g (without auxiliary weight)
Speed	33 1/3 RPM, 45 RPM, 78 RPM
Dimensions	453 x 173 x 372 mm
Weight	18 kg
Power Supply	AC 120V, 60Hz
