Ref. No. Part No. Part Name & Description Pcs Remarks
R509,10 ERDS1TJ222 1/2W 2.2K 2
R601 ERC12UGK335D 1/2W 3.3W 1
(EB,GN)
R601 ERDS1FJ4R7 1/2W 4.7 1
(PP,E)
S201,02 EVQQS204B SW 2
S203 SFDSSS01GL13 SW 1 K0KACG000006
S401 SFDSD2MSL-C SW 1
S501,02 K0F122B00099 SW 2
S601 SFDSSS5GL13P SW 1
K0KACG000007
S602 SFDSHXW01317 SW 1
K0ZZ00000489 (E,EB,GN)
T1 SFDZ122M01E POWER TRANSFORMER 1
(PP)
T1 SFDZ122S01E POWER TRANSFORMER 1
(E,EB,GN)
VR201 D2BCA54B0005 VR 1
VR303 SFDZ122N11-4 SLIDE VR 1
VR501 EVND8AA03B22 VR 1
X201 RSXB4M13J01 CRYSTAL OSCILLATOR 1 H0H419400004
X501 RSXB4M13J01 CRYSTAL OSCILLATOR 1 H0H419400004
KIT1 RFKBL120M5GK PITCH ADJ. VR 1
15. Cabinet Parts Location
15.1. Cabinet
