10. Schematic Diagram
10.1. Schematic Diagram Notes
S201:
SPEED SELECTOR (33-1/3r/min) switch.
S202:
SPEED SELECTOR (45 r/min) switch.
S203:
START/STOP switch in “OFF” position.
S401:
STYLUS ILLUMINATOR switch in “ON” position.
S501:
PITCH RESET switch in “ON” position.
S502:
PITCH SELECT (±8%/±16%) switch in “±16%” position.
S601:
POWER switch in “ON” position.
S602:
VOLTAGE SELECTOR switch in “220-240V” position. [E,EB,GN]
VR201:
BRAKE ADJUSTMENT VR.
VR303:
PITCH CONTROL ADJUSTMENT VR.
VR501:
PITCH CONTROL ±0% ADJUSTMENT VR.
- The voltage value and waveforms are the reference voltage of this
measured by DC electronic voltmeter (high impedance) and
oscilloscope on the basis of chassis. / Accordingly, there may
21
