Technics SL-1200GLDE - Page 5

- (GN): SL-1200GLDGN
- (PP): SL-1200GLDPP
- Capacity values are in microfarads (uF) unless specified otherwise,
P=Pico-farads (pF) F=Farads (F)
- Resistance values are in ohms, unless specified otherwise, 1K=
1,000 (OHM), 1M=1,000k (OHM)
- The marking <RTL> indicates the retention time is limited for this
item. After the discontinuation of this assembly in production, it
will no longer be available.
3.1. Electric Parts
Note:
- The part no. of the PITCH CONTROL P.C.B. ASS’Y (PCB3) has been
changed, but the P.C.B. diagram remains unchanged. / When
repairing, please refer to the original REP3458BA-S drawing.
Ref.No. Difference of Parts No. Part Name & Description Pcs
Remarks
SL-1210M5G SL-1200GLD
CN101
EMCS0360L K1KA04B00056
PLUG 1
Change
CN102
EMCS0460L K1KA05B00047 PLUG 1
Change
CN103
EMCS0760L TJS1A8140 PLUG
1
Change
PCB3
REP3458BA-S REP3736B-S PCB ASS’Y, PITCH CONTROL 1 1
[
RTL]
Change
3.2. Cabinet Parts, Accessory Parts and Packaging Parts
Note:
- There is a running number inscribed on the badge attached to the
Refer No. 112 CABINET ASS’Y (RFKK1200GLDE), / but no running
number on repair parts.
5
