Technics SU-G700 Owner's Manual

16
Operations
Using digital audio output device
(16)
Using coaxial digital cable
1 Disconnect the AC power supply cord.
2 Connect this unit and a CD player, etc.
3 Connect the AC power supply cord to
this unit. ( 15)
4 Press [AMP
] to turn this unit on.
5 Press [>INPUT<] repeatedly to select
“COAX1” or “COAX2”.
• You can also select the input source by
turning the input selector knob on the unit.
6 Start playback on the connected
device.
Note
• The digital audio input terminals of this unit can
only detect the following linear PCM signals.
For details, refer to the operating instructions of
the connected device.
- Sampling frequency:
Coaxial digital input
32/44.1/48/88.2/96/176.4/192 kHz
Optical digital input
32/44.1/48/88.2/96 kHz
- Number of quantization bits:
16/24 bit
You can connect the CD player, etc. with coaxial digital
cable (not supplied)/optical digital audio cable (not
supplied) to this unit and play back music.
Optical digital audio cable
(not supplied)
CD player, etc.
Coaxial digital cable
(not supplied)
Using optical digital audio cable
1 Disconnect the AC power supply cord.
2 Connect this unit and a CD player, etc.
3 Connect the AC power supply cord to
this unit. ( 15)
4 Press [AMP
] to turn this unit on.
5 Press [>INPUT<] repeatedly to select
“OPT1” or “OPT2”.
• You can also select the input source by
turning the input selector knob on the unit.
6 Start playback on the connected
device.

Technics SU-G700 Specifications

General

Type	Integrated Amplifier
Power Output (8Ω)	70 W + 70 W (1 kHz, T.H.D. 0.5%)
Power Output (4Ω)	140 W + 140 W (1 kHz, T.H.D. 0.5%)
Input Sensitivity/Impedance Line	200 mV / 47 kΩ
Input Sensitivity/Impedance Phono	2.5 mV / 47 kΩ
Speaker Impedance	4Ω - 16Ω
USB-B Input	Yes
Coaxial Input	1
Standby Power Consumption	0.3 W
Weight	12.3 kg
Signal-to-Noise Ratio Phono	83 dB (IHF-A)
Digital Inputs	Coaxial, Optical, USB-B
Analog Inputs	1 (Phono)
Analog Outputs	1 Line
Dimensions	430 x 148 x 428 mm
