Technics SU-G700 Owner's Manual

10
Control reference guide
This unit
(10)
  
 

  
01 Standby/on button ( )
• Press to switch the unit from on to standby
mode or vice versa. In standby mode, the
unit is still consuming a small amount of
power.
02 Power indicator
• Blue: The unit is on.
• Off: The unit is in standby mode.
03 Headphones jack
• When a plug is connected, the speakers and
PRE OUT terminals do not output sound.
( 22)
• Sound is not output from headphones jack
while “MAIN IN” is selected as input source
of this unit. ( 20)
• Excessive sound pressure from earphones
and headphones can cause hearing loss.
• Listening at full volume for long periods may
damage the user’s ears.
04 Volume knob
• -- (min), 1 to 100 (max)
• To display the volume, set “VOLUME
Display” to “On”. ( 25)
05 Display
• Information such as input source, etc. is
displayed. ( 32)
06 Input selector knob
• Turn this knob clockwise or anticlockwise to
switch the input source.
07 Peak power meter
• Display the output level. 100 % is the rated
output ( 34).
• Peak power meter does not work while the
light is turned off.
08 LAPC indicator ( 26)
09 Remote control signal sensor
• Reception distance: Within approx. 7 m
(23 ft) directly in front
• Reception angle: Approx. 30° left and right

Technics SU-G700 Specifications

General

Type	Integrated Amplifier
Power Output (8Ω)	70 W + 70 W (1 kHz, T.H.D. 0.5%)
Power Output (4Ω)	140 W + 140 W (1 kHz, T.H.D. 0.5%)
Input Sensitivity/Impedance Line	200 mV / 47 kΩ
Input Sensitivity/Impedance Phono	2.5 mV / 47 kΩ
Speaker Impedance	4Ω - 16Ω
USB-B Input	Yes
Coaxial Input	1
Standby Power Consumption	0.3 W
Weight	12.3 kg
Signal-to-Noise Ratio Phono	83 dB (IHF-A)
Digital Inputs	Coaxial, Optical, USB-B
Analog Inputs	1 (Phono)
Analog Outputs	1 Line
Dimensions	430 x 148 x 428 mm
