18
Operations
Using turntable (PHONO)
(18)
PHONO
EARTH
Using PHONO cable
1 Disconnect the AC power supply cord.
2 Connect this unit and a turntable.
3 Connect the AC power supply cord to
this unit. ( 15)
4 Press [AMP
] to turn this unit on.
5 Press [>INPUT<] repeatedly to select
“PHONO”.
• You can also select the input source by
turning the input selector knob on the unit.
6 Start playback on the connected
turntable.
Note
• When connecting a turntable with a built-in
PHONO equalizer, connect the PHONO cable
to the analog audio input terminals (LINE1 IN or
LINE2 IN) of this unit. ( 19)
• When connecting a turntable with a PHONO
earth lead, connect the PHONO earth lead to
the PHONO EARTH terminal of this unit.
Minimizing sound distortion
If sound distortion occurs when using the analog
audio input terminals, setting the attenuator to
“On(-3dB)”/”On(-6dB)”/”On(-10dB)” may improve
the sound quality.
• The factory default is “Off”.
You can connect the turntable with PHONO cable (not
supplied) to this unit and play back music.
PHONO cable (not supplied)
PHONO earth lead
(not supplied)
Turntable
1 Press [AMP].
2 Press [MENU].
3 Press [
], [ ] repeatedly to select
“Attenuator” and then press [OK].
4 Press [
], [ ] to select “On(-3dB)”/
”On(-6dB)”/”On(-10dB)” and then
press [OK].
Reducing low frequency noise
Reduces the low frequency noise caused by the
warpage of record.
• The factory default is “Off”.
• You can also set this menu while “LINE1” or
“LINE2” is selected as input source of this unit.
1 Press [AMP].
2 Press [MENU].
3 Press [
], [ ] repeatedly to select
“Subsonic Filter” and then press [OK].
4 Press [
], [ ] to select “On” and then
press [OK].
To Next Page
