Technics SU-G700 Owner's Manual

20
Operations
Using this unit as power amplifier
(20)
You can connect the AV receiver, control amplifier, etc. with
analog audio cable (not supplied) to this unit and use this unit as
power amplifier.
AV receiver, control
amplifier, etc.
Set the volume of the AV receiver,
control amplifier, etc. to minimum before
connecting.
While using this unit as power amplifier,
the volume adjustment with this unit is
disabled. Adjust the volume little by little
with the connected device.
Do not input the audio signal from PRE
OUT/LINE OUT terminals to the MAIN IN
terminals of this unit. Doing so may cause
malfunction.
Analog audio cable
(not supplied)
Using analog audio cable
1 Disconnect the AC power supply cord.
2 Connect this unit and AV receiver,
control amplifier, etc. after minimizing
the volume of the device.
3 Connect the AC power supply cord to
this unit. ( 15)
4 Press [AMP
] to turn this unit on.
5 Press [>INPUT<] repeatedly to select
“LINE2”.
• You can also select the input source by
turning the input selector knob on the unit.
6 Press [AMP].
7 Press [MENU].
8 Press [
], [ ] repeatedly to select
“Input Mode” and then press [OK].
9 Press [
], [ ] to select “MAIN IN” and
press [OK].

Technics SU-G700 Specifications

General

Type	Integrated Amplifier
Power Output (8Ω)	70 W + 70 W (1 kHz, T.H.D. 0.5%)
Power Output (4Ω)	140 W + 140 W (1 kHz, T.H.D. 0.5%)
Input Sensitivity/Impedance Line	200 mV / 47 kΩ
Input Sensitivity/Impedance Phono	2.5 mV / 47 kΩ
Speaker Impedance	4Ω - 16Ω
USB-B Input	Yes
Coaxial Input	1
Standby Power Consumption	0.3 W
Weight	12.3 kg
Signal-to-Noise Ratio Phono	83 dB (IHF-A)
Digital Inputs	Coaxial, Optical, USB-B
Analog Inputs	1 (Phono)
Analog Outputs	1 Line
Dimensions	430 x 148 x 428 mm
