21
Specifications
■
GENERAL
Power supply
AC 120 V,
60 Hz
Power consumption 63 W
Power consumption
in standby mode
(Network standby
On)
2.0 W
Power consumption
in standby mode
(Network standby
Off)
0.5 W
Dimensions
(W×H×D)
430 mm × 98 mm ×
368 mm
Mass Approx. 6.5 kg
Operating
temperature range
0 °C to 40 °C
Operating humidity
range
35 % to 80 % RH
(no condensation)
■
AMPLIFIER SECTION
Output power
40 W + 40 W
(1 kHz, T.H.D. 1.0 %, 8 ,
20 kHz LPF)
80 W + 80 W
(1 kHz, T.H.D. 1.0 %, 4 ,
20 kHz LPF)
Load Impedance 4 - 16
Frequency Response
PHONO (MM)
20 Hz - 20 kHz
(RIAA DEVIATION ±1 dB,
4 )
LINE
20 Hz - 40 kHz
(-3 dB, 4 )
DIGITAL
20 Hz - 80 kHz
(-3 dB, 4 )
Input sensitivity/Input impedance
LINE 200 mV / 23 k
PHONO (MM) 2.0 mV / 47 k
■
Bluetooth
®
SECTION
Bluetooth
®
system
specification
Bluetooth
®
Ver.5.1
Wireless equipment
classification
Class 1 (4 mW)
Supported profiles A2DP, AVRCP
Supported codec AAC, SBC
Frequency band 2.4 GHz band FH-SS
Operating distance
Approx. 10 m Line of
sight
*
1
*
1: Prospective communication distance
Measurement environment:
Temperature 25 °C/Height 1.0 m
Measure in “Mode1”
■
Wi-Fi SECTION
Standard
IEEE802.11a / b / g / n /
ac / ax
Frequency Band
2.4 GHz band
5 GHz band
Security WPA2™
• The WLAN feature of this product shall
exclusively be used inside buildings.
■
TERMINALS SECTION
Headphones Jack
Stereo, 6.3 mm
5 mW, 32 (VOL MAX)
USB-A (Front) Type A Connector
Support Memory
Capacity
2 TB (max)
Maximum
number of folders
(albums)
800
Maximum
number of files
(songs)
8000
File system FAT16, FAT32, NTFS
USB port power DC OUT 5 V 0.5 A MAX
■
TUNER SECTION
Frequency Modulation (FM)
Preset memory 30 stations
Frequency range
87.9 MHz to 107.9 MHz
(200 kHz step)
87.5 MHz to 108.0 MHz
(100 kHz step)
Antenna terminals 75 (unbalanced)
