Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
R674 ERDS2FJ473 47K 1
R675,76 ERDS2FJ103 10K 2
R677 ERDS2TJ105T 1M 1
R678 ERDS2FJ102 1K 1
R679 ERTD2ZHK153T 15K 1
R680 ERDS2FJ273 27K 1
R681-83 ERDS2FJ102 1K 3
<JACK P.C.B.>
PCB7 SXPG238711B JACK PCB 1 <RTL>
C701,02 QCBG1H473ZFA 0.047U 2 F1E1H473A001
C705-07 QCBG1H473ZFA 0.047U 3 F1E1H473A001
C709-16 QCBG1H473ZFA 0.047U 8 F1E1H473A001
CN701 K1MN20A00047 CONNECTOR 1
CN702 QJSG022AA CONNECTOR 1 K1FB104B0023
D701 RVD1SS133TA DIODE 1 B0AACK000004
D702 RVD1SS133TA DIODE 1 B0AACK000004
D703 RVD1SS133TA DIODE 1 B0AACK000004
D704 RVD1SS133TA DIODE 1 B0AACK000004
D705 RVD1SS133TA DIODE 1 B0AACK000004
D707 RVD1SS133TA DIODE 1 B0AACK000004
D708 RVD1SS133TA DIODE 1 B0AACK000004
IC701 PC900V IC 1 B3PAE0000002
JK701 K4BK01H00001 VIDEO OUT 1
JK702 QJJG020AA MIDI THRU 1
JK703 QJJG020AA MIDI OUT 1
JK704 QJJG020AA MIDI IN 1
JK706 QJJG010AA JACK 1
JK707 QJJG019AA JACK 1
JK708 QJJG019AA JACK 1
JK709 SJSG1390A FC 1 K1CB108B0027
L701 QLQGT3T131LA COIL 1
L703 QLQGT3T131LA COIL 1
L704 QLQGT3T131LA COIL 1
L705 QLQGT3T131LA COIL 1
L706 QLQGT3T131LA COIL 1
L708 QLQGT3T131LA COIL 1
L709 QLQGT3T131LA COIL 1
L710 QLQGT3T131LA COIL 1
L711 QLQGT3T131LA COIL 1
Q701 2SA1015TPE2 TRANSISTOR 1 B1ACCF000016
R701 ERDS2FJ221 22 1
R703 ERDS2FJ220 22 1
R704 ERDS2FJ221 22 1
R706 ERDS2FJ220 22 1
R707 ERDS2FJ221 220 1
R708 ERDS2FJ331 330 1
R709 ERDS2FJ332 3.3K 1
R711 ERDS2FJ102 1K 1
R712 ERDS2FJ152 1.5K 1
R713-18 ERDS2FJ102 1K 6
SW701 QSSGT016AA SW 1 K0D112B00112
66
