Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
<INV P.C.B.>
PCB8 SXPG238811B INV PCB 1 <RTL>
C801 ECUV1C104KBV 0.1U 1 ECJ1VB1C104K
C802 ECEA1AKS221 6V 220U 1
C803 ECQV1H104JZ 0.1U 1
C804 ECCW3F180JGE 18P 1
C805 ECUV1C104KBV 0.1U 1 ECJ1VB1C104K
CN801 K1MN20B00049 CONNECTOR 1
CN802 SJPG1JS140A CONNECTOR 1
CN803 RJP4G27ZA CONNECTOR 1 K1KA04A00063
CN804 K1KA02B00124 CONNECTOR 1
L803 QLBG005A COIL 1
L804 QLQGT1B101KA COIL 1 G0C101K00030
Q801,02 2SD0592ARA TRANSISTOR 2
R801,02 ERJ3GEYJ472V 4.7K 2
T801 QTDG005A TRANSFORMER 1 G4F1A0000003
Z801-03 EXBV8V220JV 22X4 3
<ASUB P.C.B.>
PCB9 SXPG238811A ASUB PCB 1 <RTL>
C820 ECJ1VB1H102K 0.001U 1
C821 ECUV1H080DCV 8P 1 ECJ1VC1H080D
C822 ECUV1C104KBV 0.1U 1 ECJ1VB1C104K
C823 ECUV1H471KBV 470P 1 ECJ1VB1H471K
C824 ECJ1VC1H151J 150P 1
C825 ECUV1H471KBV 470P 1 ECJ1VB1H471K
C826-28 ECJ1VC1H151J 150P 3
C829,30 ECEA1EKA470B 25V 47U 2
C831,32 ECJ1VC1H151J 150P 2
C833 ECUV1H471KBV 470P 1 ECJ1VB1H471K
C836-38 ECJ1VC1H151J 150P 3
C841 ECEA1CKS100 16V 10U 1
CN820,21 QJUG05309AA CONNECTOR 2
D820-25 MA2J11100L DIODE 6
D826 MA8062LTX DIODE 1 MAZ80620LL
IC820 TC7WU04FU IC 1 C0JBAB000339
Q820 2SB0709ARL TRANSISTOR 1
Q821 2SD0601AQL TRANSISTOR 1
Q822 2SB0709ARL TRANSISTOR 1
Q823 2SD0601AQL TRANSISTOR 1
Q824 2SB0709ARL TRANSISTOR 1
Q825 2SD0601AQL TRANSISTOR 1
Q826-28 2SB0709ARL TRANSISTOR 3
Q829 2SD0601AQL TRANSISTOR 1
Q830 2SB0709ARL TRANSISTOR 1
Q831 2SD0601AQL TRANSISTOR 1
Q832 2SB0709ARL TRANSISTOR 1
Q833 2SD0601AQL TRANSISTOR 1
Q834,35 2SB0709ARL TRANSISTOR 2
Q836 2SD0601AQL TRANSISTOR 1
Q837 2SB0709ARL TRANSISTOR 1
Q838 2SD0601AQL TRANSISTOR 1
67
