Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
Q839,40 2SB0709ARL TRANSISTOR 2
Q841,42 2SD0601AQL TRANSISTOR 2
Q843 2SB0709ARL TRANSISTOR 1
Q844 2SD0601AQL TRANSISTOR 1
Q845 2SB0709ARL TRANSISTOR 1
Q846 2SD0601AQL TRANSISTOR 1
Q847,48 2SB0709ARL TRANSISTOR 2
Q849 2SD0601AQL TRANSISTOR 1
Q850-52 2SB0709ARL TRANSISTOR 3
Q853,54 2SD0601AQL TRANSISTOR 2
Q855 2SB0709ARL TRANSISTOR 1
Q856 2SD0601AQL TRANSISTOR 1
Q857 2SB0709ARL TRANSISTOR 1
Q858 2SD0601AQL TRANSISTOR 1
Q859 2SB0709ARL TRANSISTOR 1
Q860,61 2SD0601AQL TRANSISTOR 2
R820 ERJ3GEYJ102V 1K 1
R821,22 ERJ3GEYJ332V 3.3K 2 D0GB332JA002
R823 ERJ3GEYJ102V 1K 1
R824,25 ERJ3GEYJ471V 470 2
R826 ERJ3GEYJ472V 4.7K 1
R827 ERJ3GEYJ152V 1.5K 1
R828 ERJ3GEYJ471V 470 1
R829 ERJ3GEYJ472V 4.7K 1
R830 ERJ3GEYJ822V 8.2K 1 D0GB822JA002
R831 ERJ3GEYJ821V 820 1
R833 ERD2FCVG471T 1/4W 470 FUSE TYPE 1
R834 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R835 ERJ3GEYJ153V 15K 1
R836 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R838-40 ERD2FCVG471T 1/4W 470 FUSE TYPE 3
R841,42 ERJ3GEYJ472V 4.7K 2
R843 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R844,45 ERJ3GEYJ472V 4.7K 2
R846 ERJ3GEYJ153V 15K 1
R847 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R848,49 ERD2FCVG471T 1/4W 470 FUSE TYPE 2
R850 ERD2FCG101 100 1
R851-54 ERJ3GEYJ472V 4.7K 4
R855 ERD2FCG101 100 1
R857 ERD2FCVG471T 1/4W 470 FUSE TYPE 1
R858 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R859 ERJ3GEYJ153V 15K 1
R860 ERJ3GEYJ332V 3.3K 1 D0GB332JA002
R861,62 ERD2FCVG471T 1/4W 470 FUSE TYPE 2
R863-66 ERJ3GEYJ472V 4.7K 4
R867 ERD2FCG101 100 1
R868,69 ERJ3GEYJ821V 820 2
R870,71 ERJ3GEYJ471V 470 2
<ACP P.C.B.>
68
