Technics SX-KN7000P User Manual

Ref. No. Part No. Part Name & Description
Pcs
Remarks
PCB5 SXPG232941 ACP PCB 1 <RTL>EF EH EV GN GH
PCB5 SXPG232951 ACP PCB 1 <RTL>P PC
PCB5 SXPG232961 ACP PCB 1 <RTL>GM GU GT
C1 F1B2E4720001 4700P 1
C2 ECQU2A104MN 0.1 1
F1 XBA1C20NB100 FUSE 2A 1
(P PC)
F1 XBA2C12TB0L FUSE T1.25A 1
(GU GT GM)
F2 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (GU)
F2 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (GT)
F2 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (GM)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EX)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EB)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EQ)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EG)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EF)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EH)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (EV)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (GN)
F3 XBA2C08TB0L FUSE T800MA 1
K5D801BLA001 (GH)
JK1 SJVD0203B JACK AC IN 1
L1 QLQGT2T100LA 10UHX2 1
S1 SSRG100A SW VOLTAGE SELECTOR 1
K0ZZ00000503 (GU)
S1 SSRG100A SW VOLTAGE SELECTOR 1
K0ZZ00000503 (GT)
S1 SSRG100A SW VOLTAGE SELECTOR 1
K0ZZ00000503 (GM)
<CPL P.C.B.>
PCB11 SXPG238911A CPL PCB 1 <RTL>
C1101-03 QCBG1H473ZFA 0.047U 3 F1E1H473A001
C1105 ECA0JAK221XH 6V 220U 1
C1106 QCBG1H473ZFA 0.047U 1 F1E1H473A001
C1108,09 QCBG1H473ZFA 0.047U 2 F1E1H473A001
C1110 ECA0JAK470XH 6V 47U 1
C1111-16 QCBG1H473ZFA 0.047U 6 F1E1H473A001
CN1101 K1KA07C00007 CONNECTOR 1
CN1102 K1KA04B00032 CONNECTOR 1
CN1104 SJPG2JS130A CONNECTOR 1
CN1105 K1KA12C00012 CONNECTOR 1
CN1106 K1KA06C00008 CONNECTOR 1
D1101 RVD1SS133TA DIODE 1 B0AACK000004
D1102 RVD1SS133TA DIODE 1 B0AACK000004
D1103 RVD1SS133TA DIODE 1 B0AACK000004
D1104 RVD1SS133TA DIODE 1 B0AACK000004
D1105 RVD1SS133TA DIODE 1 B0AACK000004
D1106 RVD1SS133TA DIODE 1 B0AACK000004
D1107 RVD1SS133TA DIODE 1 B0AACK000004
D1108 RVD1SS133TA DIODE 1 B0AACK000004
D1109 LN282RPXVTX3 LED 1 LNJ282RKRX02
D1110 LN382GPXVTX3 LED 1 LNJ382GKGX02
