Ref. No. Part No. Part Name & Description
Pcs
Remarks
R928 ERJ3GEYJ220V 22 1
R929-31 ERJ3GEYJ101V 100 3
SW921 JSE0013 SWITCH 1 K0L1BA000007
<SDSW P.C.B.>
PCB17 SXPG239011C SDSW PCB 1 <RTL>
CN901 SJPG2JS100A CONNECTOR 1
D901 LN282RPXVTX3 LED 1 LNJ282RKRX02
D902 LN382GPXVTX3 LED 1 LNJ382GKGX02
D903 LMW9A8BYB0A1 DIODE 1
Q901,02 2SC1815TPE2 TRANSISTOR 2 B1AACF000023
R901-03 ERDS2FJ102 1K 3
R904,05 ERDS2FJ470 47 2
R906-10 ERDS2FJ102 1K 5
R911 ERDS2FJ101 100 1
SW901-06 EVQ21405R PUSH SWITCH 6 EVQ21405RJ
<ROT P.C.B.>
PCB14 SXPG239011B ROT PCB 1 <RTL>
SW1101 QSRGT003AA ENCORDER SWITCH 1 K9AA024A0005
W1103 QEUGS4K06YY CONNECTOR 1
<HP P.C.B.>
PCB16 SXPG239011D HP PCB 1 <RTL>
C752,53 ECBT1H333KB5 0.033U 2 F1D1H333A012
C754 QCBG1H473ZFA 0.047U 1 F1E1H473A001
CN751 SJPG2JS050A CONNECTOR 1
JK751 QJJG018AA JACK 1
L751 QLQGT3T131LA COIL 1
<BEND P.C.B.>
PCB15 SXPG239011E BEND PCB 1 <RTL>
CN752 RJP4G27ZA CONNECTOR 1 K1KA04A00063
R751,52 ER0S2TKF1001 1K 2 EROS2TKF1001
VR751 EVA07015B54G VR 1 D2BKB5420001
VR752 EVA07115B14G VR 1 D2BGB14B0002
<MKB1 P.C.B.>
PCB2 SXPG232411A MKB1 PCB 1 <RTL>
D1 RVD1SS133TA DIODE 1 B0AACK000004 MKB1
D2 RVD1SS133TA DIODE 1 B0AACK000004 MKB1
D3-48 RVD1SS133TA DIODE 46 B0AACK000004 MKB1
<MKB2 P.C.B.>
PCB3 SXPG232411B MKB2 PCB 1 <RTL>
C1 ECEA0JKA470 6.3V 47 1
C2 QCBG1H104ZFA 50V 0.1 1 F1E1H104A001
C3 QCBG1H104ZFA 50V 0.1 1 F1E1H104A001
74
