Ref. No. Part No. Part Name & Description
Pcs
Remarks
C4 QCBG1H104ZFA 50V 0.1 1 F1E1H104A001
C5 TCBT1H151KB5 150P 1 F1D1H151A012
C6 TCBT1H151KB5 150P 1 F1D1H151A012
C7 TCBT1H151KB5 150P 1 F1D1H151A012
C8 TCBT1H151KB5 150P 1 F1D1H151A012
C9 TCBT1H151KB5 150P 1 F1D1H151A012
C10 TCBT1H151KB5 150P 1 F1D1H151A012
C11 TCBT1H151KB5 150P 1 F1D1H151A012
C12 TCBT1H151KB5 150P 1 F1D1H151A012
D49-96 RVD1SS133TA DIODE 48 B0AACK000004
IC1 HD74LS138P IC 1 C0JACN000001
IC2 HD74LS138P IC 1 C0JACN000001
<MKB3 P.C.B.>
PCB4 SXPG232511 MKB3 PCB 1 <RTL>
C13 QCBG1H104ZFA 50V 0.1 1 F1E1H104A001
D97-00 RVD1SS133TA DIODE 4 B0AACK000004
D101 RVD1SS133TA DIODE 1 B0AACK000004
D102 RVD1SS133TA DIODE 1 B0AACK000004
D103 RVD1SS133TA DIODE 1 B0AACK000004
D104-22 RVD1SS133TA DIODE 19 B0AACK000004
IC3 M5218AL IC 1 C0AABB000054
R1 ERDS2FJ102 1K 1
R2 ERDS2FJ101 100 1
R3 ERDS2FJ472 4.7K 1
R4 ERDS2FJ472 4.7K 1
VR1 EVSG0E1B223A VR AFTER TOUCH SENSOR ADJ 1 D3BA62230001
POWER SW
S1 QSPG1010AA POWER SW 1
SP
SP1 L0AA14A00008 14CM SP 1
SP2 QASG12P07B 12CM SP 2
SP3 L0AA06A00012 6.5CM SP 2
TRANSFORMER
T1 QTPG1M056A TRANSFORMER 1
G4C6AED00002 P PC
T1 QTPG1M057A TRANSFORMER 1
G4C6AEK00003 GU GM GT
T1 QTPG1M058A TRANSFORMER 1
G4C6AEH00001 EX EB EQ
EG
T1 QTPG1M058A TRANSFORMER 1
G4C6AEH00001 EF EH EV
GN GH
CONNECTION WITH WIRE
W1 QEUGMLW12C 20P FFC WIRE(JACK-MAIN) 1
W2 QEUGMLW34CZ 20P FFC WIRE (LCD-INV) 1
W3 QEXGSS05010A FAJ-JACK WIRE(MKB3-MAIN) 1
W4 QEXGSS05080A CONNECTOR WIRE(HP-FAJ) 1
W5 QEXGSS10020A WIRE W/CON(MAIN-SDSW) 1
W6 QEXGSS11015A CONNECTOR WIRE(SD-MAIN) 1
W7 QEXGSS12050A CONNECTOR WIRE(FAJ-MAIN) 1
W8 QEXGSS16035A CONNECTOR WIRE(MKB2-MAIN) 1
W9 QEXGVH03076B CONNECTOR WIRE(SP WIRE L) 1
W10 QEXGVH06103B CONNECTOR WIRE(SP WIRE R) 1
W11 QEXGZA34050B CONNECTOR WIRE(FDD-MAIN) 1
75
